• Model NO.：RSY-01
• Trademark：Pubtester
• Origin：Jinan, Shandong
• Production Capacity：30 Sets,Quarter

Basic Info.

Model NO. RSY-01 Trademark Pubtester Origin Jinan, Shandong Production Capacity 30 Sets/Quarter

Product Description

RSY-01 Unrestrained linear thermal shrinkage of plastic film and sheeting heat shrink tester
RSY-01 Unrestrained linear thermal shrinkage of plastic film and sheeting heat shrink tester  is professionally applicable to the determination of heat shrinking performance and dimensional stability of various films, heatshrinkable tubes, hard PVC films for tablets, and back-sheets in the fluid medium at different temperatures.



Product Features

• Controlled by micro-computer with 7-inch color touch screen, simple operation
• High-precision circuit processing technology, which is accurate and reliable
• Non-volatile liquid medium heating, wide heating range
• Digital P.I.D. temperature control technology ensures the preset temperature to be reached rapidly without any fluctuation
• Automatic timer function to efficiently guarantee the accuracy of test data
• Standard clamp wire mesh support could make the test done smoothly

Technical Specifications

Specification	RSY-01
Sample dimension	≤140mm x140mm
Temperature Range	Room Temperature ~ 200ºC
Temperature Accuracy	±0.3ºC
Heating Medium	Oil
Dimension	370(L)mm×420(W)mm×310(H)mm
Net weight	14Kg
Working Temperature	23ºC±2ºC
Working Humidity	50%±5%
Power supply	AC220V 50Hz / 120VAC 60Hz

Standards
ASTM D2732, GB/T 13519

Configuration
Standard Configuration: Instrument, Clamp Wire Meshes, Clamp Wire Mesh Support




FAQ

Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.

Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.

How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.

Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.

How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.

How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
