• Model NO.：GD-2H
• Dew Point Measuring Range：-80ºC-+20ºC
• Dew Point Accuracy：±0.5ºC(-80ºC-60ºC)
• Dimension：250*150*300 mm
• Weight：5kg
• Transport Package：Wooden Case
• Trademark：GOLD
• Origin：China
• Production Capacity：500 Sets,Month

-40ºC~+80ºC

Features:

• Fast and save gas: It can complete the detection for water content, purity and gas concentration simultaneously. After set-up and start the test, the measuring time of dew point is about 5min and SF6 purity and gases concentration is about 2min;

• Self-lock joint: The self-lock joint is imported from German which is safe, reliable and without gas leakage.

• Data storage: It can store 200 groups test results.

• Curve display: Large-screen curve display the process of dew point measurement;

• Clearly display: Dew point, micro-water(ppm), SF6 purity, SO2, H2S, CO(optional) and HF(optional) concentration, temperature, humidity, time, date, etc, are displayed by LCD.

• Built-in power supply: built-in 4Ah chargeable lithium battery, can work for 10 hours.

Vist picture
