Gurley Type Air Permeability Tester Gurley Densometer Gurley Porosity Meter

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Max Diameter of Workpiece：254mm
  • Mass Scope of Workpiece：ISO 5636-5-2013
  • Type：Air Permeability Test
  • Load Way：Mechanical Load

Base Info

  • Model NO.：XHV-26
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Touch Screen
  • Weight：0-100Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：Gurley Method
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

The mass of inner cylinder

567g

Graduations of inner cylinder

25ml between 0-100ml

50ml between 100-300ml

Height of inner cylinder

254mm

External diameter of inner cylinder

76.2mm

Height of outer cylinder

254mm

Internal diameter of outer cylinder

82.6mm

Test Area

28.6mm

Timing accuracy

±0.1s

Dimension

300mm×360mm×750mm

Weight

20Kgs

Power Supply

AC 220V, 50Hz, 100W


Gurley Type Air Permeability Tester Gurley Densometer Gurley Porosity MeterGurley Type Air Permeability Tester Gurley Densometer Gurley Porosity Meter

1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
