• Model NO.：HJ-56
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Ring Compression Sample：152*12.7mm
• Edge Pressure Sample：100*25mm
• Side Pressure Guide Block：Thick 20mm Length 120mm
• by The Source：16.220V.50h7.2A
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-56 Display Digital Weight 0-100Kg Power Source AC220V Ring Compression Sample 152*12.7mm Edge Pressure Sample 100*25mm Side Pressure Guide Block Thick 20mm Length 120mm by The Source 16.220V.50h7.2A Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product introduction:
Cardboard Ring Crimping Strength Tester is a manufacturer of cardboard and corrugated cardboard and related departments.
It is an indispensable and important test instrument for research institutions and testing institutions. Packed in paper, paper tubes, etc.
In terms of loading materials, a variety of paper quality tests can be carried out, namely five types of tests, such as ring compression (RCT), flat compression (FCT), edge compression (ECT) adhesion (PAT) and general compression resistance (CMT). All-in-one material testing equipment.

Cardboard|Paper Tube|Paper Core Ring Crimping Tester is liquid crystal display, which uses a motor to drive a screw.
Move the platen, place the sample between the upper and lower platens, and apply the specified speed
When the lower platen compresses the sample upward, the force sensor on the upper end of the upper platen feels the pressure.
force, and convert the pressure into a voltage signal and output it to the display.

Fulfill the standard:
Meet TAPPI-T472T808T810T811T818JIS-P8126G
BT26796GBT26798GBT267917GB6546 and other standards.


Capacity selection	200KG
Induction	Force sensor
Unit switching	"af" "kgf" "N", "lbf", "KN"
load resolution	1/100.000
Highest resolution	0.1N
Test remonstrance	(10+3)mm/min
Platen	Diameter 118mm
Ring compression sample	152*12.7mm
Edge pressure sample	100*25mm
Side pressure guide block	Thick 20mm Length 120mm
Display method	Touch screen operation
language selection	Chinese and English exchange
Platen parallelism	±0.02mm
Optional	Flat pressure sampler, side pressure sampler, ring pressure sampler, bonding fixture, side pressure fixture, ring pressure fixture
Dimensions	580*420*550mm
Weight	About 70ka
By the source	16.220V.50H7.2A



FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
