• Model NO.：HJ-66
• Display：Digital
• Control：Touch Screen Controller
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Sample Test Height：65mm
• Light Source：DC6V,50Hz
• Poll Time：5-60s
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Display Digital Control Touch Screen Controller Weight 0-100Kg Power Source AC220V Oil Cylinder Position No Sample Test Height 65mm Light Source DC6V/50Hz Poll Time 5-60s Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

 This product adopts an automatic turret, eliminating the need for manual rotation measurement, and is applied to: a. ferrous metals, non-ferrous metals, surface coatings, laminated metals, IC sheets. b. Ceramics, glass, agate, precious stones, metal flakes, etc. C. Electroplating layer, heat treatment, carbide layer. Hardness testing of decarburized and quench-hardened layers


Test Force	10,25,50,100,200,300,500,1000(gf)
unit optional	HRA, HRB.HRC, HR15N, HR30N, HR45N (Automatically convert  Rockwell hardness according to Vickers hardness value)
objective lens	10X (observation) 40X (measurement)
Test force selection	By changing the handwheel selection of the test force,  the instrument itself automatically recognizes it.
Measurement mode	HV
Resolution	0.25um
Measuring range	5-3000HV
measurement accuracy	Below 100HV±5%, 200HV±3%, above 400HV±2%
Load control	Automatic (load, wrap, unload)
Poll Time	5-60S
Hardness value	Manual measurement, the system automatically calculates and displays the results.
X/Y Platform	100X100mm, stroke: 25X25mm
Sample test height	65mm
Light Source	DC6V/50HZ

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
