Single-phase Digital Primary Current Injection Test Set 5000A
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
Base Info
- Model NO.：GDSL-D-5000
- Weight：100-500Kg
- Power Source：AC220V
- product name：5000A Primary Current Injection Test Set
- Output Voltage：6V
- Input voltage：AC380V, Single phase, 50Hz.
- Timer range：0.001-99999ms
- Capacity：30kVA
- Warranty：1 year
- Operating time：1min ON, 5mins OFF
- Transport Package：Standard Export Wooden Box
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan, China
- HS Code：9030339000
- Production Capacity：5000set,Year
Description
Model
Output capacity
(kVA)
Output Current
(A)
Power Supply
(V)
Opening Voltage
(V)
Power Phase
Remark
GDSL-D-500
3
500
220
6
LN
Integral
GDSL-D-1000
6
1000
220
6
LN
Integral
GDSL-D-1500
9
1500
220
6
LN
Integral
GDSL-D-2000
12
2000
220 or 380
6
LN
AB
Integral or Split type
GDSL-D-2500
15
2500
220 or 380
6
LN
AB
Integral or Split type
GDSL-D-3000
18
3000
220or 380
6
AB
Integral or Split type
GDSL-D-4000
24
4000
380
6
AB
Split type
GDSL-D-5000
30
5000
380
6
AB
Split type
GDSL-D-6000
36
6000
380
6
AB
Split type
GDSL-D-8000
48
8000
380
6
AB
Split type
GDSL-D-10000
60
10000
380
6
AB
Split type
GDSL-D-12000
72
12000
380
6
AB
Split type
GDSL-D-15000
90
15000
380
6
AB
Split type
