• Model NO.：HD-F750A
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Control and Display：Computer
• Sensor：Load Cell
• Capacity：500kg
• Unit：Kg, N, Lb
• up Plate：Diameter 200mm, Bottom Fillet R1mm
• Max Stroke：1200mm (Include Fixture)
• Test Speed：0.1-500mm,Min
• Load Decomposition Degree：1,250000
• Power：Single Phase, 220V, 50Hz
• Transport Package：Strong Wooden Case
• Specification：L*W*H: 880*510*1490mm
• Trademark：HAIDA
• Origin：Dongguan, China
• Production Capacity：150 Sets,Month

Basic Info.

Model NO. HD-F750A Control Computer Control Weight 100-500Kg Power Source AC220V Control and Display Computer Sensor Load Cell Capacity 500kg Unit Kg, N, Lb up Plate Diameter 200mm, Bottom Fillet R1mm Max Stroke 1200mm (Include Fixture) Test Speed 0.1-500mm/Min Load Decomposition Degree 1/250000 Power Single Phase, 220V, 50Hz Transport Package Strong Wooden Case Specification L*W*H: 880*510*1490mm Trademark HAIDA Origin Dongguan, China Production Capacity 150 Sets/Month

Product Description

Computer Control Mattress And Sofa Foam Compression Hardness Testing Machine
 Product Description

The Foam Compression Hardness Tester widely used in various types of metal, metal, rubber, plastics, leather shoes, clothing, textile, insulators, wire and cable, terminals and other types of materials, testing the tensile, tearing and peeling, compressive strength, bending shear and three point bending, elongation, sponge, foam and other porous elastic material of the indentation hardness and compression calculation of pressure ratio...... And other physical testing performance.

Design Standard: ISO 2439, ASTM D 3574

STANDARD FEATURES


Control and display	Computer
Sensor	Load cell
Capacity	500KG
Unit	Kg, N, LB
Up plate	Diameter 200mm, bottom fillet R1mm
Low plate	380×380mm, holes diameter 6mm, space 20mm, max stroke 200mm
Max stroke	1200mm (include fixture)
Test speed	0.1~500mm/min
Load decomposition degree	1/250000
Load accuracy	Less than 0.5%
Motor	Servo motor
Driver	Taiwan high precision ball screw
Power	Single phase, 220V, 50Hz
Weight	170KG
Dimension	510*880*1490mm
Accessories	One computer with software Sponge tensile clamp set Sponge pressure depression pressure plate

About Us
Haida international is a professional production of all kinds of testing equipment factory..Company has more than 10 years experience for Test Equipment. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.




Our Services:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
1. Pre-service
--24 Hours online service for your consult.
--Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4. Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
5.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.



FAQ:
Q:what about the products' quality?
A:Our machine has internal quality inspection departments and Third-party testing certification bodies. Internal Quality Inspection department to the finished equipment, the appearance of the instrument inspection, the instrument of the internal circuit and instrumentation testing software testing, instrument calibration, sample testing.

Q:Do you accept customization service?
A:Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements.

Q:Is it the manufacturer?Do you provide after-sales service?What about the warranty?
A:Yes,Haida international is a professional production of all kinds of testing equipment factory.Every machine from our factory has a 12 months product warranty.Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
Also, if you have different plugs needed, considerate service for different country plugs, manually switching voltage from 110V to 220V, insurance indicator light.

Q:Are your operation keypad,interface,software and manual in English version?
A:Yes.it's operation kevoad.interface.software and manual in English version if you need other languages.kindly contact us for confirmation.
