High Precision and Reliable Rapid Temperature Change Test Chamber

Guangdong Komeg Industrial Co., Ltd.
  • Type：Material Testing Machine
  • Weight：100-500Kg
  • Power Source：AC380V
  • Working Chamber Volume (L)：1000
  • Temp. Rate of Change Oc/Min：5
  • Temp. Range：-70oc~+100oc(Rapig Change Range -40oc~+85oc Liner)

Base Info

  • Model NO.：ESS-1000LL5
  • Temp. Constancy：+,-3.0oc
  • Interior Material：Stainless Steel Plate
  • Exterrior Material：Baked Painting Steel or Stainless Steel (SUS304)
  • Insulation Material：Rigid Polyurethane Foam+Glass Fiber Wool
  • Colling Mode：Water Cooled
  • Cpntroller：Touch Screen Programmable Controller
  • Observation Window：Glass Incorporating Heat Generator
  • Transport Package：Strong Plywood Case, Meet International Standard
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets,Year

Description

Specifications Model ESS-LL225LL5225LL10408LL5408LL101000LL51000LL10Working Chamber Volume(L)2254081000Temp Rate of Change( ºC/Min)510510510Performance -70ºC~+100ºC Rapid Temp Change -40ºC~+85ºC Full Linear ControlHumidity Constancy±0.5ºCTemp Constancy±3.0ºCExterior MaterialCold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless SteelInterior Material Stainless Steel Plate(SUS 304)Insulation MaterialRigid Polyurethane FoamSafety Devicesover pressure,over heat and over current protection for compressor, over temp. protection,CompressorSemi-Hermetic CompressorCooling ModeWater CooledControl systemBalanced Temperature & Humidity Control System(BTC type)HeaterIron-chrome wire heaterBlowerCentrifugal BlowerObservation WindowGlass incorporating heat generatorTemp SensorPt-100 ControllerTouch screen programmable controller Ambient Temp.+5ºC~+35ºCPowerAC 380V/50Hz 3phase 5 wires+ Ground wire Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available Features
Standard Water cooled systems
Copper tubing cooling coils with aluminum fins;
Solder-in-place components minimize leakage;
High temperature silphosed or silver soldered joints
Stainless steel drip pans in both compressor and cascade compartments contain condensate;
HFC refrigerants;

Electrical Features
Nichrome wire heating elements;
Fail safe fusible link high heat limit protection;
Door interlocks to prevent test interruption;

Air Flow Systems Features
Externally mounted fan motors;
Jackshaft assemblies on all systems to provide maximum reliability and flexibility;
Aluminum backwards-inclined blower wheels;
Vertical or horizontal air flow systems;
High velocity air provides optimum air flow across your productHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test ChamberHigh Precision and Reliable Rapid Temperature Change Test Chamber
