• Model NO.：GD-0722A
• Net Weight：300 Kg
• Dimension：1400 (Length)*800 (Width) *1600 (Height) mm
• Method：Centitrifuge Separation Method
• Transport Package：Wooden Case for Gd-0722 Asphalt Centrifugal Extrac
• Trademark：Gold
• Origin：China
• Production Capacity：100 Piece,Pieces Per Month

Basic Info.

Model NO. GD-0722A Net Weight 300 Kg Dimension 1400 (Length)*800 (Width) *1600 (Height) mm Method Centitrifuge Separation Method Transport Package Wooden Case for Gd-0722 Asphalt Centrifugal Extrac Trademark Gold Origin China Production Capacity 100 Piece/Pieces Per Month

Product Description

Bituminous Mixture Centrifugal Extractor for Testing Bitumen-Mineral Aggregate Ratio



Product Description:

Bituminous mixture centrifugal extractor extracts asphalt content in the bituminous mixture using high speed centrifugal separation methods to determine the asphalt-aggregate ratio rapidly in the bituminous mixture and it can initially screen and size aggregate.

Bituminous mixture centrifugal extractor has functions of asphalt extraction and solvent recycling. The solvent is recycled in the closed system, so it is low in the pollution of the environment. The rotation speed is set to high-low-high, so the mineral powder can be completely collected.

Bituminous mixture centrifugal extractor uses a microprocessor for data processing. The parameters, running states, and data are shown on a LCD, so it is intuitive and it is easy to be operated.

Bituminous mixture centrifugal extractor has programmable run button and manually run button, so it is easy to run, maintain, or repair the instrument.



Specification:

1. Sample quantity: 1000g~1500g;
2. Extraction accuracy: ≤0.1%;
3. Extraction time: 20~40 minutes/times;
4. Rotation speed: 5500 RPM, and 11000 RPM;
5. Ambient temperature: 5~40ºC; relative humidity ≤80%;
6. Power supply: AC 380 V;
7. Total power consumption: not more than 5 kW;
8. Pressure of cooling water: <2 bar, water temperature >12ºC;
9. Total weight: 300 kg;
10. Size: 1400 (length) ×800 (width) ×1600 (Height) mm;
11. Product name:Bituminous Mixture Centrifugal Extractor for Testing Bitumen-Mineral Aggregate Ratio
