• Model NO.：16-T0174
• Control：Manual Control
• Weight：6.5kg
• Power Source：No
• Oil Cylinder Position：No
• Transport Package：Aluminum Box and Carton
• Specification：0 to 260 kPa
• Trademark：C-Tech
• Origin：China
• HS Code：90248000
• Production Capacity：10000sets,Month

Basic Info.

Model NO. 16-T0174 Control Manual Control Weight 6.5kg Power Source No Oil Cylinder Position No Transport Package Aluminum Box and Carton Specification 0 to 260 kPa Trademark C-Tech Origin China HS Code 90248000 Production Capacity 10000sets/Month

Product Description

DESCRITIONS:
16-T0174 Field inspection pocket vane tester
This tester, designed to measure the undrained shear strength (Cu) of cohesive soils, consists of a cylindrical body with a torsional spring and three interchangeable vanes of different sizes used depending upon the expected strength of the soil.
The vanes have the following dimensions:
- small size 32x16 mm (height x dia.)
- medium size 40x20 mm (height x dia.)
- large size 50.8x25.4 mm (height x dia.).
101.6 x 50.8 mm (height x dia.).
The height/diameter ratio of all vanes is 2.During operation the vane is driven for 10 cm into the soil
and then turned with the handle. Deep measures (i.e. on the top of undisturbed samples) can be obtained using the extension rod.
SPECIFICTION :

Vane dimensions(heightx dia.)	32x16 mm /40x20 mm /50.8x25.4 mm /101.6 x 50.8 mm
Measuring range	0 to 260 kPa
Torque value	5 N·m
Extension rod	included
Max deepth	3 m
