Precise Location Fault Point Underground Cable Fault Pinpointing Locator Cable Fault Locator
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- Warranty：12 Months
- Usage：Network Cable Tester, Coaxial Cable Tester
Base Info
- Model NO.：XHDD503D
- Test Region：Forming Cable
- Power：Electricity
- Certification：CE
- Customized：Customized
- Color：Black
- All Pass：100Hz ~ 1500Hz
- Highpass：150Hz ~ 1500Hz
- Signal Gain：Adjustable From 1 to 7 Gears
- Built-in Battery：8.4V
- Accuracy：0.1m
- Transport Package：Wood Case with Foam
- Specification：350*280*170 (mm)
- Trademark：XZH TEST
- Origin：China
- Production Capacity：2000PCS,Year
- Package size per unit product：35.00cm * 28.00cm * 17.00cm
- Gross weight per unit product：6.500kg
Description
Overview
Product Description
Product Parameters
Technical Data:
★Fixed-point accuracy: 0.1m
★Bandwidth: 300-1500Hz can be adjusted arbitrarily
★Gain:>80db
★Power supply: Built-in 3400mAH lithium ion battery.
Use time: continuous use time> 8 hours;
Charger: input AC220V±10%, 50Hz; Nominal output 8.4V, 1A
Charging time: <6 hours.
★Display: 5-inch color LCD, 854*480 resolution, with touch function
★Volume: host 200mmX195mmX120mm
★Weight: host 2.0kg; sensor 2.5kg
★Conditions of use: temperature -25ºC-40ºC, humidity 90%RH, altitude <4500m
