• Model NO.：HJ-66
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Weight 0-100Kg Power Source AC220V Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Differential scanning calorimeter, as a classical thermal analysis method of thermal effect under controllable programmed temperature, has been used in various occasions such as research and development, process optimization, quality control and failure analysis in the fields of various materials and chemistry. a wide range of applications.Using the DSC method, we can study the phase transition of inorganic materials, the melting of polymer materials, the crystallization process, the polymorphism of drugs, and the solid/liquid phase ratio of foods such as oils and fats. Measure physical and chemical changes related to heat, such as glass transition temperature, melting point, melting temperature, heat of crystallization and crystallization, heat of phase transition reaction, thermal stability of products, curing/crosslinking, oxidation induction period, etc.

Features of DSC Differential Scanning Calorimeter

1. Brand new furnace structure, better resolution and resolution and baseline stability; 2. Using digital gas mass flowmeter to precisely control the purge gas flow, the data is directly recorded in the database;

3. The instrument can adopt two-way control (host control, software control), with friendly interface, simple operation and easy to use.

4. It has the characteristics of good repeatability and high accuracy, especially suitable for accurate measurement of specific heat. 5. The device is easy to calibrate, has a low melting point, is fast and reliable, and has a wide range of applications.

Parameters of  DSC Differential Scanning Calorimeter

DSC range	0~±500mW
Heating rate	0.1~80ºC/min
temperature repeatability	±0.1ºC
DSC resolution	0.001mW
DSC sensitivity	0.01mW
Curve sweep	Warming scan
Gas flow	0-200mL/min
Display method	24bit color 7-inch LCD touch screen display
Parameter standard	With one-button calibration
Power	600W
Temperature range	Room temperature~600ºC
Temperature resolution	0.01ºC
DSC noise	0.001mW
DSC accuracy	0.01mW
Temperature control method	Heating: Program control Constant temperature: Arbitrary setting
Atmosphere control	Instrument automatic switching
Gas pressure	0.2MPa
Data interface	Standard USB interface
Working power	AC 220V 50Hz or customized
Brand	Hong Jin



The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
