• Model NO.：HJ-68
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Product Name：Hydraulic Press
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-68 Display Digital Weight 0-100Kg Power Source AC220V Product Name Hydraulic Press Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

introduce
The CNC servo electronic press is referred to as the electronic press, and its working principle is that the ball screw is driven by the servo motor to carry out the pressure assembly operation. It can realize the whole-process closed-loop control of the press-fitting force in the press-fitting operation.

Features
1. Five-stage quick press fitting;
2. On-line press fitting quality determination;
3. Press-fit curve display;
4. Seven press-fitting modes are available;
5. 100 sets of press-fitting programs can be set;
6. Press-fit data transmission and storage.

Function:
1. Provide 30-100KN settable pressing force (set directly on the touch screen);
2. The upper and lower limits of the interference force are alarmed, and five points are compared during the pressing process;
3. Interference data storage function, which can be exported to personal computer and opened in EXCEL form for easy query;
4. The modification and calling of parameters can only be operated by entering the password. There are 9,999,999 sets of press-fitting parameters that can be stored. The administrator has the right to modify and save the parameters, and the operator only has the right to use the model selection drawing number.
5. It has the function of peak alarm, that is, for each press fitting, the pressure of the force sensor will be captured, and then the upper and lower limits will be alarmed, indicating whether the set pressure and the actual pressure are within the difference range;
6. Corresponding text prompts can be made for the alarms issued by the equipment;
7. Real-time display of the pressing curve of force and displacement pressure;
8. Realize the current pressing position with the accuracy of ±0.01MM;
9. The upper and lower limits of the final press-fitting position can be compared, and it can be detected that the parts are missing or incorrectly installed and that they are not assembled in place due to other reasons;
10. The pick-up stop position, deceleration position, and descent safety position can be set on the touch screen. compress time;
11. With manual/automatic function: when the manual function is in the mold, press the corresponding button to get the corresponding action, and the hand will stop immediately. Automatic function Press the corresponding button, the indenter goes down quickly → slow down → pressurization → pressure retention → the indenter automatically returns.
12. Equipped with two-hand button to start (the two buttons are only valid if they are pressed simultaneously within 0.5 seconds), and an emergency recovery button is provided.
13. With two-color warning light and buzzer, sound and light alarm when fault occurs.
14. With infrared safety grating protection. During the pressing process of the oil cylinder, it is detected that an object with a diameter of 25MM protrudes into the machine, and the oil cylinder immediately rises and alarms with sound and light.


The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


Hongjin's services:
If you encounter any problems during future testing, we promise we will reply you within 48 hours and provide a solution within 3 working days. We can provide operation video and English operation manual. We can provide video conferencing.
1. Pre-sales service
    --24-hour online service for your consultation.
    -- Help with choosing the right model, and a range of services, people, advice.
   --Provide laboratory planning and pre-sales technical guidance.
2. Intermediate service
    -- give you the best offer
    --Provide discounts on multiple sets of orders
    -- Do the customer's request:
    --Choose a payment term that is convenient for you.
    --Prompt production and delivery, keep you informed.
    -- Invoice value can be provided according to your needs to reduce tax.
3. After-sale service
   --1 year warranty service and lifetime maintenance.
   --Technical engineers can provide 24-hour after-sales guidance.
   --Replacement of some parts
   --Remote control technical consultation
   --Machine lifetime maintenance service
4. Commitment:
We will sign a letter of commitment at the same time as signing the contract, which will increase your confidence in us.
5. Good packaging:
Simulation animation customers cover with bubble film before putting them into wooden boxes, which not only has good shock absorption, impact resistance, heat sealing, but also has the advantages of non-toxic, odorless, moisture-proof and corrosion-proof, and good transparency.
