• Model NO.：GDQH-31W
• Display：Needle
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Plywood Case
• Specification：ISO
• Trademark：HV HIPOT
• Origin：Wuhan, China

Basic Info.

Model NO. GDQH-31W Display Needle Control Manual Control Weight 0-100Kg Power Source AC220V Transport Package Plywood Case Specification ISO Trademark HV HIPOT Origin Wuhan, China

Product Description

GDQH-31W Portable SF6 Gas Recovery Device for Ring Network Distribution Network


General Information

GDQH-31W Portable SF6 Gas Recovery Device (MINI) is used in the manufacturing plant of SF6 gas insulated electrical equipment and operation & scientific research departments to fill electrical equipment with SF6 gas and recover SF6 gas from electrical appliances used or tested.
At the same time, it is purified and compressed and stored in the storage tank. Suitable for ring network distribution network below 50kV.


Features


• Recover the gas in electrical equipment;
• Drying the recovered and refilled SF6 gas.
• Compress storage and bottle filling of SF6 gas in electrical appliances.
• Directly press SF6 into a small gas cylinder (provided by yourself) for storage.

Technical Specifications


Compressor	High voltage oil-free compressor
Maximum exhaust pressure	38Bar
Exhaust volume	2.0m3/h, SF6 gaseous 0.5kg/min
Volume	500*300*400mm
Weight	25kg
Power	220V 850W
Connector	DN8-DN20/cylinder connector (customizable). 2pieces high-pressure pipes. DN6
