Product Description

Product Introduction
Cable path meter is a special instrument used to accurately detect the direction and depth of buried cables within a certain range;
The path detection is completed by the cooperation test of the path signal generator and the path signal receiver; through the cooperative operation between them, the cable path can be accurately positioned within the approximate cable buried range.

The main components of path detectionPath detection is mainly composed of path signal generator and receiver

 Path signal generator
The path signal generator can generate high-power audio output signals, and the receiver receives the audio signals to complete the path detection function.
The main technical indicators are as follows:
a) Large output power, strong anti-vibration and anti-interference ability, stable and reliable;
b) It has reliable over-current, open-circuit, and short-circuit protection functions;
c) Output frequency: audio;
d) Output signal: intermittent, 0~50Vpp
e) Working power supply: 220V (1±10%) 50Hz (1±5%);
f) Output power: 100W;
g) Output current: 0~2A;
The path signal generator uses 220V mains power supply, and the output signal voltage and power vary with different loads. If the output terminal is short-circuited, the device will be protected immediately. After the load short-circuit state is eliminated, press the start button and the device will resume normal operation.


Path receiver
Receive the audio signal sent by the cable, so as to accurately detect the buried depth and direction of the cable.
The main performance indicators of the receiver:
Gain ≥100dB, accurate and quick search
LED display signal strength, observation is intuitive and concise
Lithium battery power supply, longer battery life
One-key switch, easy to operate
Digital volume adjustment, the sound is clearer
Easy to use, you can use it when you turn on the probe and connect it
Positioning accuracy: ±5% of depth
Depth measurement accuracy: ±5% of depth
Depth measurement range: 5 meters
