• Model NO.：GDC-9560B
• Temperature control range：room temperature 5-400ºC
• Temperature increasing steps ：16 steps
• Increasing speed：0.1-40ºC,min
• External event：4 channels
• Detector：FID, TCD, ECD(optional), FPD(optional)
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• Production Capacity：2000 Sets,Year

Detection limit≤2×10-11g/s (Hexadecane/isooctane)Baseline noise≤5×10-14ABaseline shift≤1×10-13A/30minLinear range≥ 106

TCD(thermal conductivity detector)

SensitivityS≥2500mV•ml/mg (benzene/methylbenzene) (enlarge 1,2,4,8 times for option)Baseline noise≤20μVBaseline shift≤30μV/30minLinear range≥104

ECD (electron capture detector) optional

Detection limit1×10-13g/ml (Hexachlorocyclohexane/isooctane)Baseline noise≤0.03mVBaseline shift≤0.2mV/30minLinear range103Radioactive souce63Ni

FPD (flame photometric detector) optional

Detection limit(S)≤5×10-11g/s, (P)≤1×10-12g/s(parathion-methyl/ absolute ethyl alcohol)Baseline noise≤3×10-13ABaseline shift≤2×10-12A/30minLinear rangeSulphur≥102, phosphorus≥10
