• Model NO.：HARTIP2500
• HS Code：9024102000
• Production Capacity：5000,Per Year

Principle

Leeb hardness measurement

Accuracy / Repeatability

±0.3% @ HL=800 / ±2HL

Display High contrast color

TFT 240 x 320

Hardness scale

HL/HRC/HRB/HB/HV/HS/HRA/σb

Measuring range

HL100-960 / HRC0.9-79.2 / HRB1.2-140 / HB1-1878 / HV1-1698 / HS0.5-128 / HRA7-88.5 / σb(rm)24-6599N/mm2

Probe

Digital probe D/ C/DC/D+15/DL/E

Wireless probe D C/DC/D+15/DL/E (optional), Reading probe D (optional)

Materials and conversion

curves 11 common metal materials, 75 curves

Memory 999 data

999 data

Statistics function

Average / Max. / Min. / S. value

Re-calibration

Allowed by user

Indicator

Low battery

Language,

En g l i s h ,   German,

Interface USB / Bluetooth (optional)

USB / Bluetooth (optional)

Power on/off

Auto / Manual

Power supply

AA alkaline battery / USB power supply

Working environment

-20°C~+70°C

Dimension (mm) 1

145x70x30

Net weight (g)

145

Standards

Conforming to ASTM A956, DIN 50156, GB/T 17394-1998

Standard package

HARTIP 2500
HARTIP 2500 main unit 1
Digital probe D 1
Test block D 1
Small support ring 1
Cleaning brush 1
Probe cable 1
Software
USB cable 1
Operation manual 1
Test Certificate 1
Carrying case 1

Optional accessories

Digital probe C/DC/D+15/DL/E
Reading probe D
Wireless probe D C/DC/D+15/
DL/E
Special support rings
Standard support ring for
probe D
Small support ring
Impact body D
Carbide ball tip D
Test block D with certificate
Test block D w/o certificate
