• Model NO.：ZC-700A
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：35kg
• Power Source：220V
• Oil Cylinder Position：None
• Power Consumption：5va
• Longest Measured Distance：32km (100km for Open Wire )
• Reading Resolutionn：1m
• Detection Blind Area：1m
• Middle& High Power Cable：6kv& Above, 35kv Below.
• Low Voltage Cable：6kv Rated or Below
• High Voltage Power Cable：66kv& Above Rated Cable
• Test Way：Tdr
• Transport Package：Wooden Box
• Specification：225mm*165mm*125mm
• Trademark：KvTester
• Origin：China
• HS Code：9031809090
• Production Capacity：500,Month

Basic Info.

Model NO. ZC-700A Accuracy Grade 1 Load Way Electronic Load Loading Method Static Load Display Digital Control Manual Control Weight 35kg Power Source 220V Oil Cylinder Position None Power Consumption 5va Longest Measured Distance 32km (100km for Open Wire ) Reading Resolutionn 1m Detection Blind Area 1m Middle& High Power Cable 6kv& Above, 35kv Below. Low Voltage Cable 6kv Rated or Below High Voltage Power Cable 66kv& Above Rated Cable Test Way Tdr Transport Package Wooden Box Specification 225mm*165mm*125mm Trademark KvTester Origin China HS Code 9031809090 Production Capacity 500/Month

Product Description

Description

To test the HV arcing fault of cable, earthing high &low resistance, short circuit and breakage of the cable, poor contact, etc. If equipped with fault locator, it can decide the exact broken position of the cable ,applies to power cable in various type, voltage and communication cable



Prodcut Features

1. Multi functional, safe, fast speed and accurate. It uses LV impulse method and HV flashover method to test, can test kinds of fault of the cable, if equipped with sound locator, can accurately the position of the fault point
2. High precision, adopts high-speed sampling technique, A/D sampling speed is 100MHz, resolution is 1m, detection blind area is 1m.
3. High degree of intelligence, test results auto displayed by LCD.
4. Can store and review the waveform and parameters, these information will not loss after power off.
5. Dual display, compare the measured waveform and normal waveform of the fault cable, benefit to further detection of the fault.
6. With function of wave form expansion ratio, change the proportion of the waveform, expand the waveform to test.
7. Directly display the direct distance or relative distance between fault point and measured point.
8. Can modify the speed according different measured cable.
9. Portable design , small in volume , with rechargeable battery, easy to carry and operate.

Product Technical Parameter
Cable Fault Detector

Model:	ZC-700A
Applications	This cable fault detector can test all types power cable (voltage class 1kV~35kV) , local cable, FM communication cable, coaxial cable, short circuit, earth, high resistance leakage, high resistance flashover fault of the metal overhead lines, and the broken & poor contact of the cable. It also can test the length of the cable and the speed of the electric wave on the cable.
Longest measured distance	32km (100km for open wire )
Detection blind area:	1m
Reading resolution	1m
Power consumption:	5VA
Service conditions	temperature: 0ºC~+40ºC(extreme temperature: -10ºC~+ 50ºC) Relative humidity: 40ºC(20~90)%RH Atmospheric pressure (86~106) Kpa
Dimension	225mm×165mm×125mm
