Lab Equipment High Quality LCD Screen Digital Display Static Computerized Servo Control Reinforce Bar Steel Strand Universal Testing Machine
Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.- After-sales Service：yes
- Warranty：one-year
- Type：Universal Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：TBTUTM-1000B
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Place of Origin：Jiangsu, China (Mainland)
- Brand Name：Tbt
- Model Number：We-600b Series
- Power：Hydraulic
- Usage：Universal Testing Machine
- Transport Package：Standard Exporting Packing
- Specification：ISO9000
- Trademark：TBT
- Origin：Nanjing, China
- HS Code：90158790
- Production Capacity：50 Sets Per Month
Description
Overview
Product ParametersModel TBTUTM-1000B Max. Capacity(KN) 1000 Range 4%-100%F.S.(Full range, without gear) Reading accuracy Grade 1 Error ±1% Column Number 6 Width between two column 510 Max tensile space(mm) 600 Bending test Distance between two points (mm) 100-400 Round specimen clamp diameter(mm) Ø20-Ø40 Flat specimen clamp thickness (mm) 0-40 Stroke (mm) 200 Pistons rise fastest speed(mm/min) 80 Beam rising speed (mm/min) 310 Displacement reading relative error ±1% Motor capacity (KW) 2.5 Main unit dimension (mm) 960×620×2100 Oil source cabinet dimension (mm) 540×540×1300 Main unit weight 2200 Oil source cabinet weight 210
