OEM Intelligent Type Automatic Measurement Function DC Hipot Test Set with Printer
Wuhan NANR Electric Co., Ltd.- After-sales Service：Yes
- Warranty：1 Year Warranty
- Type：Universal Testing Machine
- Display：Digital
- Control：Manual and Automatic
- Weight：0-100Kg
Base Info
- Model NO.：ZGF-Z
- Power Source：AC220V
- Rated Voltage：0 -300kv
- Rated Current：0 - 10mA
- Rated Power：0- 3000W
- Accuracy：1.0% (Full Scale) + , - 2digits
- Overvoltage Setting Error：<1%
- 0.75 Switching Error：<1%
- Power Supply：Single-Phase 220V, 50Hz
- Operation Method：Intermittent Use, 30 Minutes for Rated Load
- Relative Humidity：< 85%Rh
- Altitude：<2000m
- Temperature：-15 - 50 Centigrade
- Transport Package：Plywood Case
- Trademark：NANR
- Origin：Wuhan China
- HS Code：9030339000
- Production Capacity：5000 Sets Per Year
Description
less than 2000m
Remarks:Voltage: AC 100V /110V /115V /120V /200V /220V /230V /240V can be customized;
Input frequency: 50Hz/60Hz can be customized;
3. Product characteristics
(1) It adopts large-screen dot matrix LCD with man-machine interaction function;
(2) Fully automatic measurement function for zinc oxide surge arresters, with good repeatability and high precision;
(3) Automatic test function: the test voltage can be preset, and the output voltage can be maintained at a constant voltage;
(4) Automatic timing function: It can preset the boost time of the standard test voltage, and automatically timing after the voltage rises to the standard test voltage, after finishing timing, it automatically drops voltage.
(5) The high voltage over-voltage setting is adopted with a microprocessor, which has high precision and good reliability;
(6) Retain the manual test mode;
(7) Data storage function: Instantly capture test parameters and automatically save test results
(8) According to the theory of electromagnetic compatibility, it is combined special shielding, multi-stage isolation and grounding protection measures to prevent damage during discharge;
(9) With print function can print the test result in-time.
4. Patent Certificate
As a professional manufacturer of intelligent DC high voltage generator (DC high voltage test set), we have professional R&D team to master the core technology, we had awarded the design patent certificate in 2018.
