• Model NO.：Ceyear 1465
• Power Source：AC 100-240V
• Weight：〉10Kg
• Installation：Direct Connected
• Customized：Non-Customized
• Transport Package：Aluminum Alloy Box
• Specification：W*H*D=482mm*152mm*582mm
• Trademark：Ceyear
• Origin：China
• HS Code：8543209090
• Production Capacity：500 Pieces , Year

Frequency propertiesFrequency range1465C: 100kHz-10GHz
1465D:100kHz~20GHz
1465D+H06:
10MHz-20GHz
1465F:100kHz~40GHz
1465H:100kHz~50GHz
1465L:100kHz~67GHz
(Max. frequency of 70GHz)FrequencyN (internal YO harmonic number)100kHz≤f≤250MHz1/8250MHz<f≤500MHz1/16500MHz1/81GHz1/42GHz1/23.2GHz110GHz220GHz440GHz8Frequency resolution0.001HzFrequency switching time<20ms (typical value2)Timebase aging rate (typical value3)5×10 -10 /day (after 30-day continuous power-on)Reference outputFrequency10MHzPower>+4dBm, to 50ΩReference inputFrequency1-50MHz, 1Hz stepPower-5dBm - +10dBm, 50Ω impedanceSweep propertiesSweep modeStep sweep, list sweep, analog sweep, power sweepHigh-precision analog sweep
(option H03)Max. sweep speed100kHz≤f≤500MHz25MHz/ms500MHz50MHz/ms1GHz100MHz/ms2GHz200MHz/ms3.2GHz400MHz/msSweep accuracy0.05 Sweep width (for 100ms, within the maximum width of 100ms as specified)Power propertiesMin. powerModelStandard packageOption H01A/B1465C/D/F-20dBm-110dBm (-135dBm configurable)1465D+ option H06-10dBm-90dBm (-125dBm configurable)1465H/L-20dBm-90dBm (-110dBm configurable)Max. power
(25±10°C)Frequency rangeStandard packageH01A/B programmable step attenuator optionH05 high-power output optionOptions H01A/B+H051465C/D    100kHz≤f≤20GHz15dBm15dBm203dBm203dBm1465D+ option H06    10MHz≤f≤20GHz28dBm27dBm------1465F    100kHz≤f≤9GHz12dBm12dBm20dBm20dBm9GHz12dBm12dBm17dBm17dBm1465H/L    100kHz≤f≤15GHz5dBm5dBm17dBm17dBm15GHz5dBm5dBm13dBm13dBm30GHz≤f≤67GHz5dBm4dBm8dBm8dBmPower accuracy
(25±10°C)StandardFrequency     power (dBm)>2010~20-10~10-20~-10100kHz≤f≤2GHz---±0.8dB±0.6dB±1.5dB2GHz<f≤20GHz---±0.8dB±0.8dB±1.5dB20GHz<f≤40GHz---±1.0dB±0.9dB±1.8dB40GHz<f≤50GHz------±1.3dB±1.8dB50GHz<f≤67GHz------±1.5dB±2.0dB1465D+ H06 enhanced high-power output option500MHz<f≤20GHz±1.2dB±0.8dB±0.9---H01A/B programmable step attenuator optionFrequency     power (dBm)>2010~20-10~10-70~-10-90~-70100kHz≤f≤2GHz---±0.8dB±0.6dB±0.7dB±1.5dB2GHz<f≤20GHz---±0.8dB±0.8dB±0.9dB±1.8dB20GHz<f≤40GHz---±1.0dB±0.9dB±1.0dB±2.0dB40GHz<f≤50GHz------±1.3dB±1.5dB±2.5dB50GHz<f≤67GHz------±1.5dB±1.8dB±3.0dB1465D+ H06 enhanced high-power output option10MHz≤f≤500GHz---±1.3dB±0.9dB±1.0dB±1.8dB500MHz<f≤20GHZ±1.2dB±0.8dB±0.8dB±1.1dB±2.0dBPower resolution0.01dBPower temperature stability0.02dB/ºC (typical value)Output impedance50Ω (Rating4)VSWR
(Internal fixed amplitude) (typical value)100kHz≤f≤20GHz<1.620GHz<1.840GHz<2.0Max. reverse power0.5W (0V DC) (rating)Spectrum purity5Harmonic
(at +10dBm or Max. specified output power, whichever is lower)FrequencyStandard packageH06 enhanced high-power option100kHz≤f≤10MHz<-25dBc---10MHz<f≤2GHz<-30dBc<-25dBc2GHz<f≤6GHZ
(1465B)<-30dBc---2GHz<f≤9GHz<-55dBc<-35dBc9GHz<f≤14GHz<-55dBc<-27dBc14GHz<f≤20GHz<-55dBc<-30dBc20GHz<f≤67GHz<-50dBc (typical value)---Sub-harmonic (at +10dBm or Max. specified output power, whichever is lower)100kHz≤f≤10GHzNon10GHz<-60dBc20GHz<-50dBcNon-harmonic(At 0dBm, beyond 3kHz offset)FrequencyStandard packageOption H04100kHz≤f≤250MHz<-58dBc<-58dBc250MHz<f≤3.2GHz<-74dBc<-80dBc3.2GHz<f≤10GHz<-62dBc<-70dBc10GHz<f≤20GHz<-56dBc<-64dBc20GHz<f≤40GHz<-50dBc<-58dBc40GHz<f≤67GHz<-44dBc<-52dBcSingle side band phase noise
(dBc/Hz, +10dBm or Max. output power, whichever is smaller)Frequency1Hz10Hz100Hz1kHz10kHz100kHz100kHz≤f≤250MHz-------104-121-128-130250 MHz<f≤500MHz-------108-126-132-1360.5 GHz<f≤1GHz-------101-121-130-1301 GHz<f≤2GHz-------96-115-124-1242 GHz<f≤3.2GHz-------92-111-120-1203.2 GHz<f≤10GHz-------81-101-110-11010 GHz<f≤20GHz-------75-95-104-10420 GHz<f≤40GHz-------69-89-98-9840 GHz<f≤67GHz-------64-84-92-92H04 ultra low phase noise option100kHz≤f≤250MHz-64-92-105-123-138-142250 MHz<f≤500MHz-67-93-111-126-138-1420.5 GHz<f≤1GHz-62-91-105-123-138-1381 GHz<f≤2GHz-57-86-100-117-133-1332 GHz<f≤3.2GHz-52-81-96-113-128-1283.2 GHz<f≤10GHz-43-72-85-105-120-12010 GHz<f≤20GHz-37-66-79-98-114-11420 GHz<f≤40GHz-31-60-73-91-108-10840 GHz<f≤67GHz-26-54-68-85-102-102Modulation propertiesFrequency modulation
(option H02A)Maximum deviation: N×16MHz (N: YO harmonic number)
Accuracy (at 1kHz, N×20kHz≤deviations<N×800kHz):
<± (3.5%× set frequency offset +20Hz)
Modulation rate (3dB band width, 500kHz frequency offset): DC-10MHz
Distortion (at 1kHz, N×20kHz≤ distortion <N×800kHz): <1%Phase modulation
(option H02A)Maximum deviation:
Normal mode: N×16rad (N: YO harmonic number)
Broadband mode: N×1.6rad (N: YO harmonic number)
Accuracy (at 1kHz, N×0.2rad≤deviations
<± (5% of deviation +0.01 rad)
Modulation rate (3dB bandwidth):
Narrowband mode   DC - 1MHz (typical value)
Broadband mode   DC - 10MHz (typical value)
Distortion (at 1kHz, N×0.8rad≤deviationsAmplitude modulation
(option H02A)Max. depth: >90%
Modulation rate (3 dB bandwidth, 30% modulation depth): DC-100kHz
Accuracy (1kHz modulation rate,30% modulation depth): ± (6% of setting +1%)
Distortion (1kHz modulation rate, linear mode, THD, 30% modulation depth): <1.5%Pulse modulation
(option H02B) 500MHz - 3.2GHz> 3.2GHzSwitch ratio>80dB>80dBRise and fall time<20ns<20nsMin. pulse width for internal fixed amplitude1μs1μsMin. pulse width for non fixed amplitude0.1μs0.1μsNarrow Pulse modulation
(option H02C) 50MHz~3.2GHzMore than 3.2GHzOn/off ratio>80dB>80dBRise/fall time<15ns<10nsMin. pulse width ALC on1μs1μsMin. pulse width ALC off30ns20nsInternally modulated signal generator
(option H02A/B/C)There are 3 independent signals respectively for frequency/phase modulation, amplitude modulation and low frequency output signals.
Waveform: Sine, square, triangle, sawtooth, noise, double sine, sweep sine.
Frequency range: DC -10MHz for sinusoidal wave, double sine, sweep sine wave; 0.1Hz-100kHz for square wave, triangular wave and sawtooth wave.
Frequency resolution: 0.1Hz
Low frequency output: Amplitude: 0-5Vpeak (rating), to 50Ω load.
Pulse modulation signal: Pulse width: 20ns - (42s-10ns), pulse period: 100ns-42s, resolution: 10nsGeneral propertiesRF output port1465C: N (female), impedance: 50Ω
1465D: 3.5mm (male), N (female) (option H91), impedance: 50Ω
1465F: 2.4mm (male), impedance: 50Ω
1465H/L: 1.85 mm (male), impedance: 50ΩDimensionsW×H×D=426mm×177mm×460mm (excluding. handle, foot mat and footing)
W×H×D=510mm×190mm×534mm (including handle (option H93), foot mat and footing)Weight<28kg (as per model and option configuration)Power supply100-120VAC, 50-60Hz; or 200-240VAC, 50-60Hz (self-adaptive)Power consumptionless than 350WTemperature rangeOperating temperature: 0 - +50ºC; storage temperature: -40 - +70ºCNotes:
1. 1465 series signal generators, after stored for 2h at the ambient temperature and preheated for 30min, meet all performance indexes, within the given operating range.
2. Typical value is a supplementary item given with a set value, only for reference by users.
3. +16dBm for 1465B
4. Rating is a predicated performance, which is useful in product description, but not covered by product warranty.
5. Spectrum purity index is in dot frequency non modulation mode.
6.  The test power is set to +15dBm for SSB phase noise of 100kHz≤f≤250MHz. For option H06, the frequency range is 100MHz≤f≤250MHz, and the frequency range less than 100MHz is not guaranteed.
