Test Instrument

Paper Tensile Machine Testing Digital Tensile Testing Machine Digital Computer Paper Tensile Test Machine Universal Tensile Testing Machine

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service:12 Monthes Excellent After Service
  • Warranty:12 Monthes Excellent After Service
  • Max Diameter of Workpiece:900mm
  • Mass Scope of Workpiece:100n, 200n, 500n
  • Type:Tensile Testing Machine
  • Maxcapacity:5000n

Base Info

  • Model NO.:XHL-02S
  • Accuracy Grade:0.5
  • Load Way:Electronic Load
  • Loading Method:Dynamic Load
  • Display:Digital
  • Control:Computer Control
  • Weight:0-100Kg
  • Power Source:AC220V
  • Oil Cylinder Position:Under
  • Transport Package:Plywood Case
  • Specification:100N, 200N, 500N, 1000N, 2000N, 5000N
  • Trademark:XHINSTRUMENTS
  • Origin:China
  • HS Code:9024800000
  • Production Capacity:5000 PCS, Year1

Description

Basic Info.

Model NO. XHL-02S Accuracy Grade 0.5 Load Way Electronic Load Loading Method Dynamic Load Display Digital Control Computer Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Under Transport Package Plywood Case Specification 100N, 200N, 500N, 1000N, 2000N, 5000N Trademark XHINSTRUMENTS Origin China HS Code 9024800000 Production Capacity 5000 PCS/ Year1

Product Description

Auto tensile Tester is professionally applicable to the determination of force properties of various flexible packaging materials, with high precision (0.5% of full scale) and multiple test ranges. The instrument is designed with different independent test modes and could perform tests at different test speeds to meet various test conditions. Intelligent software facilitates to operate the instrument and provides data analysis and comparison functions.

Test Standard:
This instrument conforms to various national and international standards as follows:

ISO 37, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T4850-2002, GB/T12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB/T 17590, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, JIS P8113, QB/T 2358, QB/T 1130

Basic Application (For Plastic and Paper Test)


Test of Tensile Strength and Elongation Rate
Test of Tensile Strength and Elongation Rate
Tear Resistance Test
Heat Seal Strength Test
90 Degree Peel Test
180 Degree Peel Test

Note: can add test function and related test fixtures to test other various materials.

Features:


10.5% of full scale effectively ensures accurate test results
2High stiffness structure which can endure at least 5KN
3Multi Units can selected for different testing requirement
4900mm extra-long stroke satisfies the test needs of various materials with extreme elongation rate
5Different test range of load cells and test speeds to meet different test requirements
6The instrument is controlled by micro-computer with menu interface, large touch screen operation.
7Intelligent designs of over-travel protection, overload protect, automatic position reset and power failure memory for safe test operation
8Professional operating software support statistical analysis of group specimens, superposition analysis.
9Connect professional software for uniform management of test results and test reports
10High performance ball screw transmission and stepper motor to make the machine
running quietly
11Thermal Print can print related test results fast and clear.

Technical Parameter:

Load cell 500N (Standard)
50N, 100 N, 250 N, 1000N (optional)
Measurement Range0.5-100% of load cell capacity
Accuracy of Test Force 0.5% FS
Resolution0.001mm
Displacement Resolution 0.001mm
Accuracy of Deformation 1% FS
Testing Speed1-500mm/min
Effective Testing Stroke 900mm (after install grips)
Dimension 500mmx420mmx1550mm
Weight80Kgs
Power Supply220V±10V 50HZ

Paper Tensile Machine Testing Digital Tensile Testing Machine Digital Computer Paper Tensile Test Machine Universal Tensile Testing MachinePaper Tensile Machine Testing Digital Tensile Testing Machine Digital Computer Paper Tensile Test Machine Universal Tensile Testing Machine1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
