• Model NO.：GT-DSC-MUL
• Accuracy Grade：0.5
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Transport Package：Wooden Package
• Specification：50kg
• Trademark：GT-TEST
• Origin：Beijing
• HS Code：9024800000
• Production Capacity：100

Basic Info.

Model NO. GT-DSC-MUL Accuracy Grade 0.5 Load Way Electronic Load Loading Method Static Load Display Digital Control Computer Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Under Transport Package Wooden Package Specification 50kg Trademark GT-TEST Origin Beijing HS Code 9024800000 Production Capacity 100

Product Description

 Differential Scanning Calorimeter

Standards

• ISO11357-6, isothermal OIT

Highlights

1. Industry computer control
2. Software Full-automatic performance
3. Functions

1. Glass transition temperature
2. Phase transition
3. Melting, thermal enthalpy value
4. Oxidation induction period

Application
DSC is an intelligent and miniaturized thermal analysis instrument, which is applicable for oxidation induction time(OIT) test, as well as Glass transition temperature, Phase transition, Melting, thermal enthalpy value.
It provides an analysis method for organic, inorganic, polymer, mineral, petrochemical products, textile, medicine, etc. Functions like magnification and narrowing of the graph make the friendly interface easy to operate.
Features

1. Industrial computer is introduced with rich information, e.g. set temperature, sample temperature, Oxygen flow rate, Nitrogen flow rate, DSC signal, status of switches, flow rate zeroing.
2. Integrated furnace, user-selectable rate for temperature rising up/down.
3. Double temperature sensors ensure high repeatability of test results. One sensor installed on the wall of furnace, the other at the bottom of sample for collecting real test temperature. Patented controlling technology is applied to make the temperature of the sample reach to the set point by controlling the temperature on the wall of the furnace.
4. Digital mass-flow meter switches the flow rate of Oxygen/Nitrogen automatically with fast switching speed.
5. Standard sample provided for calibrating constant temperature coefficient.
6. Simplified to one-key operation. Tens of commands can be combined on your demands, making operation more easier. Also support self-programming function.

Technical specifications
1  Temperature range: room temperature to 500ºC ( higher temperature customized)
2  Temperature resolution: 0.1ºC
3  Heating rate: 0.1 ~ 80 ºC / min
4  DSC range: 0 ~ ± 200 mW
5  DSC resolution: 0.01 mW
6  DSC sensitivity: 0.1 mW
7  Working power supply: AC 220 v 50 hz
