• Model NO.：A1LX20
• Mass Scope of Workpiece：<900kg
• Type：Balancing Machine
• Maxcapacity：<1000KN
• Accuracy Grade：0.5
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：1000-2000Kg
• Power Source：AC380V
• Oil Cylinder Position：Top
• Product Name：Automatic Vertical Balancing Machine
• Usage：Disc Shape Rotor or Fans
• Milling Method：Double Cutter Drilling
• Power：AC380V or Custom
• Pneumatic：0.4-0.6MPa
• Gross Weight：1500 Kg
• Delivery Detail：Within 35 Days
• Control System：PC Windows
• Certificate：CE, ISO, SGS, BV.
• Transport Package：Fumigated Wood Box
• Specification：900*1600*1800mm
• Trademark：JP
• Origin：Shanghai
• HS Code：9031100090
• Production Capacity：100
• Package size per unit product：2400.00cm * 2100.00cm * 1630.00cm
• Gross weight per unit product：1058.000kg

Data RotorsMax Mass of Workpiece(kg)35Max Diameter of Workpiece (mm)450Balancing Unit ParameterSpindle Speed (r/min)800Motor Power(kw)1.5Min Achievable Residual Unbalance Amount (emar)5g· mm/kgUnbalance CorrectionMaximum Milling Depth(mm)Depending on rotorMaximum Milling Width(mm)Depending on rotorCutting Speed(r/min)900Cutting Spindle Motor Power(kw)2.2Maximum Milling Angle(degree)0-90Milling Cutter Range(mm)60-125Machine ParameterPower(kw)6Weight(ton)1.5Dimensions(mm)900*1600*1800

Certificates
