China Portable High Performance Automatic Current Transformer Tester CT PT Analyzer 1000A Potential Transformer CT Vt Characteristic Tester IEC Standard
EP HIPOT ELECTRIC CO., LTD.- Type:Universal Testing Machine
- Accuracy Grade:0.5
- Display:LCD
- Control:Computer Control
- Weight:0-100Kg
- Power Source:AC220V
Base Info
- Model NO.:EPCP Series
- Testing Purposes:Protective CT
- IEC:IEC60044-1, IEC60044-6 CT,PT Standard
- Current Transformer (CT):Magnetization Curve, Turn Ratio Test,Polarity More
- CT Turns Ratio:Less Than 25000A,5A(5000A,1A)
- PT Turns Ratio:1~500kv
- Output Current:0~1000A
- Secondary Winding Resistance:0.1~300ohm
- Secondary Real Load:5~1000va
- Power Supply Output Waveform:Sine Wave
- Magnetization Curve:Yes
- Turns Ratio Test:Yes
- Polarity:Yes
- Current Injecting:Yes
- Resistance Test:Yes
- Withstand Test:Power Frequency
- Transport Package:Plywood Case with Warter Proof Plastic
- Specification:400 *200 * 260(mm)
- Trademark:EP Hipot
- Origin:Wuhan, China
- HS Code:9030820000
- Production Capacity:2000,Year
Description
Major Technical ParametersOperational Power Supply: AC220V±20V, 50~60Hz Power Supply Output Waveform: Sine Wave Single Tester Output Voltage of Excitation Characteristic: 0~2500V Excitation Output Current: 0~20 A Single machine output current of turns ratio test 0~1000A CT ratio measurement range 5~25000A/5A(5000A/1A) PT ratio measurement range 1~500kV Load Range 5~1000VA Resistance measurement range 0.1~300Ω Error: ≤0.5%(0.2%*Reading+0.3%*Range) Operating Temperature: -10ºC~+40ºC Relative Humidity: <90RH% Altitude ≤1000m Overall Dimension (Length × Width × Height): 400 *200 * 260(mm) Weight: ≤23 Kg
