High Performance High Precision Hand-held Signal Measuring And Output Meter Multifunction Process Calibrator
Wuhan GDZX Power Equipment Co., Ltd.- After-sales Service：Provide lifelong after-sales service
- Warranty：1 Year
- Relative humidity：0~90%RH, non-condensation
- Weight：650 grams
- Dimensions：200mm*96mm*47mm
- Communication mode：RS232
Base Info
- Model NO.：ZXTX
- Transport Package：Carton,Wooden Case
- Specification：With the change of technical scheme
- Trademark：GDZX
- Origin：Hubei
- Production Capacity：500 Pieces,Month
Description
Function
Range
Accuracy(% Reading+counts)
ZXTX-2025
ZXTX-1825
DC V
0~60.000V(Upper Display ±30V)
0.02%+2
0.05%+2
DC mA
0-24.000mA(Upper Display ±24mV)
0.02%+2
0.05%+2
DC mV
-15.000mV~80.000mV
0.02%+2
0.05%+2
80.00mV~125.00mV
Resistance
(2 wires, 3wires)
0.00Ω~440.00Ω
0.15Ω
0.25Ω
400..00Ω~3200.00Ω
1.0Ω
1.5Ω
Resistance (4wires)
0.00Ω~440.00Ω
0.1Ω
0.15Ω
400..00Ω~3200.00Ω
0.5Ω
1.0Ω
Frequency
1.000Hz~99.999Hz
0.01%+1
0.02%+1
1000.0Hz~9999.99Hz
10.000kHz~99.999kHz
TC
J,K,T,E,R,S,B,N
RTD
Pt100,Pt1000, Cu50, Cu100
Function Range Accuracy(% Reading+counts) ZXTX-2025 ZXTX-1825 DC mA(Active/Passive) 0-24.000mA 0.02%+2 0.05%+2 DC V 0~10.000V 0.02%+2 0.05%+2 DC mV -15.000mV~99.999mV 0.02%+2 0.05%+2 100.00mV~125.00mV Resistance 10.00Ω~440.00Ω 0.15Ω 0.25Ω 400.0Ω~3200.0Ω 1.0Ω 1.5Ω Frequency 0.20Hz~200.00Hz 0.01%+1 0.02%+1 200.0Hz~2000.0Hz 2.000kHz~20.000kHz TC J,K,T,E,R,S,B,N RTD Pt100,Pt1000, Cu50, Cu100 Product picture
Device display
About GDZX
Wuhan GDZX Power Equipment Co.,Ltd.is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
Shipping and packaging
