• Model NO.：TH-150-E
• Humidity Range：20%~98%R.H.
• Temperature Rising：Approx 0.1~3.0c,Min
• Humidity Falling：Approx. 0.1~1.2c,Min
• Compressor：French Brand
• Test Hole：Dia. 100mm
• Viewing Window：W250*D300mm
• Transport Package：Wooden Case
• Specification：150 L
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：8514109000
• Production Capacity：100 Sets,Month

Overview Product Description

Climate Chamber Programmable Temperature Humidity Testing Chamber is also called environment testing machine, used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

Product ParametersTemperature humidity test chamber Technical Parameters:

Model

 TH-80(A~F)

 TH-150(A~F)

 TH-225(A~F)

 TH-408(A~F)

 Internal Dimension

WxHxD (mm)

 400x500x400

 500x600x500

 600x750x500

 600x850x800

External Dimension WxHxD (cm)

 950x1650x950

 1050x1750x1050

 1200x1900x1150

 1200x1950x1350

 Temperature Range

 Low Temperature(A:25°C  B:0°C  C:-20°C  D:-40°C  E:-60°C  F:-70°C)

 High Temperature 150°C

 Humidity Range

20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier)

Indication relolution/Distribution uniformity of temperature and humidity

 0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H.

Indication relolution/Distribution uniformity of temperature and humidity

 ±0.5°C; ±2.5% R.H.

Temperature Rising / Falling Velocity

Temperature rising approx. 0.1~3.0°C/min
temperature falling approx. 0.1~1.5°C/min;
( Falling Min.1.5°C/min is optional)

 Inner and Outer Material

Interior material is SUS 304# stainless steel, exterior is stainless steel or see cold-rolled steel with paint coated.

 Insulation Material

Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials

 Cooling System

Wind cooling or water cooling, (single segment compressor-40°C, double segment compressor -70°C)

 Protection Devices

Fuse-free switch, overloading protection switch  for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection

 Optional Accessories

 Inner door with operation hole , Recorder, Water Purifier, Dehumidifier

 Compressor

 French Tecumseh Brand, Germany Bizer Brand

 Power

 AC220V 1 3 lines, 50/60HZ ,  AC380V 3 5 lines , 50/60HZ

 Approx. Weight (Kg)

 150

 180

 250

 320

Detailed PhotosExhibition

Climate Chamber Programmable Temperature Humidity Testing Chamber
