• Model NO.：BZW-3000D
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：180kg
• Power Source：AC220V
• Transport Package：Wooden Case
• Specification：840*500*1650mm
• Trademark：BOZWANG
• Origin：Changzhou, China
• Production Capacity：1000 Set,Year

Max.measure range 10kNTest accuracy level 0.5 level;Test force measurement range 0.2%-100%FSTest force relative indication error within ±1% indicating valueTest force resolution Max.1/±300000 test force(no change resolution)Absolution deviation of displacement indicating value within ±0.5% indicating valueDisplacement resolution 0.003mmAdjustable range of force control degree 0.1-5%FS/SAbsolute deviation of force control degree within ±1% set valueAdjustable range of beam speed 0.05-500mm/minAbsolution deviation of beam speed within set valueControl range of constant force, constant deformation and constant displacement 0.5%--100%FS;Control precision of constant force, constant deformation and constant displacement when set value is <10%FS ,within ±1% set value Set value is ≥10%FS ,within ±0.1% set value;Maximum pulling stroke 1100mmEffective stretching space(net space) 850mmEffective test width 420*420mm;Dimension 840*500*1650mmPower 220V     50Hz     0.4kWWeight About 180kg      Jiangsu Bozhiwang Automation Equipment Co., Ltd. is a large-scale intelligent wire processing equipment manufacturer in China,located in the center of the beautiful and rich Yangtze River Delta---China's famous industrial equipment manufacturing base Changzhou City, Jiangsu Province.

      The company covers an area of 40,000 square meters and a building area of 45,000 square meters with more than 400 employees,including more than 300 outstanding technicians. The company has successively passed ISO9001, QS-9000, CE certification, TUV certification, and developed a number of products with independent intellectual property rights, and obtained more than 60 invention patents, more than 100 utility model patents and 100 new appearance patents, the technology and comprehensive strength of product research and development ranks the top among the nationwide.

      In the production process, the company strictly follows the ISO:9001 quality standard for daily production and management. It mainly focuses on the automotive, photovoltaic and new energy industries and has developed and produced a series of automatic processing equipment with
high quality, stable performance and high efficiency.

      Mainly include automotive wiring harness/HSD/FAKRA radio frequency wire harness/new energy wiring harness and other related semi-automatic and fully automatic intelligent production lines, automatic double ends terminal machine with seal inserting, automatic ribbon cable terminal machine, automatic single-double-end terminal crimping machine, automatic wire stripping machine,JB box automation equipment, new energy automation equipment, and a complete set of equipment series for various semi-automatic wire harness processing. With the increasing annual output of the company, it has reached an annual output of more than 20,000 sets of intelligent assembly lines and various wire harness processing equipment, and the production equipment has the characteristics of high precision, high degree of automation, and strong supporting performance of the whole machine.
