• Model NO.：YTAT-216
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Top
• Inner Size(W*H*D)：600*600*600mm
• External Size(W*H*D)：1330*1400*1900mm
• Capacity：1000 Liters
• Temp. Range：10 Degrees---300degrees
• Humidity Range：20% Rh--98%Rh
• Temp. Fluctuation：+,-0.5 Degree
• Humidity Fluctuation：+,-0.5%Rh
• Color：Ivory or Other
• Interior Chamber Material：SUS#304 Stainless Steel Plate
• Exterior Chamber Material：Stainless Steel Plate + Powder Coated
• Transport Package：Well Packed in Strong Plywood Cases.
• Specification：CE, SGS, TUV certified.
• Trademark：Yuanyao
• Origin：Dongguan, China(Mainland)
• HS Code：9032100000
• Production Capacity：100 Sets,Month

Specification1ModelYTAT-101YTAT-216Internal Dim.W×H×D(mm)450×500×450600×600×600External Dim.W×H×D(mm)1180×1350×7501330×1450×900Temp RangeRoom temp +10ºC--300ºCFeaturesTemp Constancy±0.5ºCTemp Uniformity±2ºC -- ±3ºClndication Resolution±0.1ºCHeat-up Time(min)3040MaterialExteriorStainless steel plate + Powder CoatedInteriorSUS # 304 stainless steel piateInsulationFiberglass woolSystemsCirculationsiroco fanHeatingChrome steel strip wire heaterControlPID electronic digital control+S.C.ROther ComponentsVacuum glass observation window lighting,environmental control indicator lightsExperiment separation shelves,rotation experiment pams,ventilation adjusment mechanism Airch ang Rate5 -- 200 (3 --250)times/per hourSefety DevicesOverheating prevention circuit-breaket,control systen,breakdown indicator rightPower Source[K.W.]AC 1Ψ 220V;60/50Hz710Comply with ASTM D2436, JIS K7212, DIN 50011, BS 2648, IEC-540.Air Change Rate for StandardsStandardsAir Change RateJIS-K212, JIS-K6723         JIS-A5756, JIS-C3004         JIS-C3005, JIS-K6301up 1 time/hrASTM-D2436, ASTM-D573         ASTM-5374, ASTM-D5423-93100-200 times/hrUL-746B100-200 times/hrUL-1581.62.4445-250 times/hrISO/DIS 45771 time/hrBS-67468-20 times/hrBS-9038-20 times/hrIEC-5408-19 times/hr




Except Climatic Precision Hot Aging Test Machine, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal

Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp.

Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test

equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

Welcome to enquire and purchase !
