Class 100 Clean Safe High Temperature Resistance Chamber
Guangdong Yuanyao Test Equipment Co., Ltd.- Type：Universal Testing Machine
- Weight：100-500Kg
- Power Source：AC220V
- Inner Size：600*900*500mm
- External Size：1150*1650*740mm
- Volume：270 Liters
Base Info
- Model NO.：YPO-270
- Temp. Fluctuation：+,-0.3 Degree
- Color：Ivory
- Interior Chamber Material：SUS#304 Stainless Steel Plate
- Exterior Chamber Material：Stainless Steel Plate + Powder Coated
- Filters：HEPA Filters
- Indication Resolution：0.1degree , 1 Degree
- Heat up Time：30 Mins
- Transport Package：Strong Wood Carton
- Specification：SGS, TUV certified
- Trademark：Yuanyao
- Origin：China
- HS Code：9032100000
- Production Capacity：100 Sets,Month
Description
SpecificationMODEL YPO-072 YPO-270 YPO-480 YOP-600 YPO-720 Internal Sim.WHD(mm) 400×450×400 600×900×500 800×1000×600 1000×1000×600 1200×1000×600 External Dim.W×H×D(mm) 750×1100×550 1150×1650×740 1300×1700×840 1500×1750×840 1850×1750×840 Temp.Range Room Temp.+10ºC---+200ºC(300ºC) Ferformance Temp.&Humi,Constancy ±0.3ºC Temp.&Humi,Constancy ±0.1ºC AT 200ºC;±1.5% AT 300ºC Indication Resolution 0.1ºC Heat-up Time( min.) Approx.30min. Material Filters HEPA Filters Exterior and Interior Iron Sheet+Baked Enamel; SUS#304 stainless steel piate Insulation Fiberglass Wool SYSTEMS Cirulation Circle Fan Heating Chrome Steel Strip Wire Heater Controller Electric Digital Control+S.S.R. door Single-Wing Double-Wing Other Components Environmental Control Indicator Lights, Experiment Separation Shelves(2 pcs). Sevey Devices Overheating Prevention Circuit breaker, Control System,Breakdown Indicator Light. Power Source[K.W.] AC 1Ψ 220V ; 3Ψ 380V 60/50Hz Customization of inner chamber size, temperature range, etc.
