High Temp. High Pressure Ipx1~Ipx9 Water Proof Test Chamber
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece：700mm
- Mass Scope of Workpiece：900kg
- Type：High Temp. High Pressure Water Proof Test Chamber
- Maxcapacity：N,a
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：YWT-1000-9K
- Loading Method：Static Load
- Display：Digital
- Control：Controller
- Weight：100-500Kg
- Power Source：AC380V
- IP Grade：Ipx9k
- Temp. Range：R.T.+5~+80degrees
- Inner Chamber Size：100X100X100mm
- Water Jet Nozzle Diameter：1.8mm, Heterotypic Nozzle
- Nozzle Quantity：4PCS
- Water Pressure：8000~10000kpa
- Water Flow：5~16L,Min, Adjustable
- Rotating Table Speed：0~10r,Min, Adjustable
- Inner Chamber Material：SUS#304 Stainless Steel Plate
- Power：AC 3 Phase 380V 50Hz
- Transport Package：Strong Wood Carton
- Specification：IEC60529
- Trademark：Yuanyao
- Origin：China
- HS Code：9031809090
- Production Capacity：100 Sets,Month
Description
Control system1. Adjustment device: Spraying pipe and rotating platform adopt step-less speed regulating. 2. Electric conponents: Main components are imported. Main configurations: Water pump, water flow meter, speed reducer, presure meter, ball valve, filter, etc. Testing standards This equipment comply with IPx1, IPx2,IPx3, IPx4, IPx5, IPx6 water resistance test standards of JIS D0203-1994, standard of IEC60529, standard CB4208-93 and other technical standards equivalent to thest rules. Package Packing is by strong plywood box suitable for long distance transportation. Warranty Free parts warranty service for 12 months, during the warranty period, we will provide free parts maintenance service, over the warranty period, lifelong maintenance also available with charges.
