Automatic Ring and Ball Softening Point Apparatus with 4 Sample Positioins

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D36
  • Power Supply：AC(220±10%)V, 50Hz
  • Measurement Range：5ºC~160ºC
  • Temperature Resolution：0.1 ºC

Base Info

  • Model NO.：SPT-III
  • Heating Rate：(5.0±0.5) ºC, Min
  • Beaker Volume：900ml
  • Total Power Consumption：<700W
  • Dimension：400mm*300mm*490mm
  • Weight：15kg
  • Test Position：4 Units
  • Display：LCD
  • Test Method：Ring and Ball Apparatus
  • Application：Asphalt and Bitumen Testing
  • Function：Determine Softening Point of Petroleum Asphalt
  • Stirring Speed：(0~300) R,Min
  • Transport Package：Plywood Case
  • Specification：Automatic
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Power supplyAC(220V±10%)V, 50Hz2Measurement range(1) Heating medium: distilled water(softening point <=80 ºC) +5 ºC~+80ºC
(2) Heating medium: glycerin (softening point > 80 ºC) 32 ºC~160 ºC.3Temperature resolution0.1 ºC4Heating rateit will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes5Heating power600 W6Communication portRS-232C7Volume of beaker900ml8Ambient temperature15ºC~35ºC9Relative humidity≤85%10Maximum power consumption700 W11Dimension400mm×300mm×490mm (L*W*H)




Factory overviewAutomatic Ring and Ball Softening Point Apparatus with 4 Sample Positioins
Customer Feedback

Germany
Automatic Ring and Ball Softening Point Apparatus with 4 Sample Positioins
USA
Automatic Ring and Ball Softening Point Apparatus with 4 Sample Positioins
Package
Automatic Ring and Ball Softening Point Apparatus with 4 Sample Positioins
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
