Simulated Environment Quickly Transforms Cold and Thermal Shock Boxes/Test Chamber

Ai Si Li (China) Test Equipment Co., Limited
  • After-sales Service：Lifelong Technical Service Support
  • Power Supply：AC380V
  • Certification：CE, TUV, ISO, SGS, BV
  • Warranty：2 Years
  • Temperature Range：-70~+150 Degree C
  • Humidity Range(Optional)：20%~98%R.H.

Base Info

  • Model NO.：TS-150-B
  • Temperature Recovery Time：Less Than 5mins
  • Conversion Time：Less Than 5 Seconds
  • Temperature Control Accuracy：+,-0.5 Degree C
  • Distribution Accuracy：+,-2degree C
  • Compressor：French "Tecumseh" Brand
  • Internal Dimension：W600*H500*D500mm
  • Transport Package：Wooden Case
  • Specification：CE Certified
  • Trademark：ASLi
  • Origin：Guangdong, China
  • HS Code：85141090
  • Production Capacity：100 Sets,Month

Description

Overview Product Description

Product ParametersDetailed Photos

Simulated Environment Quickly Transforms Cold and Thermal Shock Boxes/Test Chamber

Simulated Environment Quickly Transforms Cold and Thermal Shock Boxes/Test ChamberSimulated Environment Quickly Transforms Cold and Thermal Shock Boxes/Test ChamberSimulated Environment Quickly Transforms Cold and Thermal Shock Boxes/Test Chamber


Thermal Shock Resistance Test Equipment Features:
1. It is divided into three zones: High temperature zone, low temperature zone, and testing zone. The test sample is in static mode.
2. Using touch-control graph control as operation interface, easy to operate.
3. Applying wind route conversation to the shock method to distribute temperature to the testing zone for cold and thermal shock measurement.
4. For high temperature shock or low temperature shock, max. Time is up to 999H, and max. Circulation cycles are 9999 times.
5. The system can be used for automatic Circulation Shock or manual selective shock.
6. Adopt binary cooling system, with quick cooling effect. Cooling method is water cooling.
7. Can entering normal temperature. RS-232 and RS-485 communication.


Our service
1.High quality guarantee.
2.Shipment with professional documents.
3.Packing as your request, with photo before shipment.
4.Reply within 48 hours and provide solution within 3 working days
5.Professional after-service from our engineers.
6.Warranty period 12 monthes.
