• Model NO.：KMH-800S
• Humidity Constancy：+,-2.5%R.H.
• Temp. Uniformity：+,-2.0oc
• Humidity Uniformity：+,-5.0%R.H.
• Heat up Time：-70 Oc~+100 Oc Within 45mins
• Pull Down Time：+20 Oc~-70 Oc Within 60mins
• Refrigeration System：Hermetic Compressor, Stage Refrigeration System
• Equipment Power：18.5kw
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Technical parameters:

Environmental Temperature and Humidity Chamber

Specifications ( at +20°C room temp. Or+25°C water temp with empty load)

Model

KMH-S series

225S

408S

800S

1000S

Interior size

W(mm)

700

700

1000

1000

H(mm)

700

750

1000

1000

D(mm)

480

800

800

1000

Exterior size

W(mm)

980

980

1280

1280

H(mm)

1890

1940

2160

2160

D(mm)

1460

1740

1750

1950

Weight(KG)

330

450

550

650

Temp. range

-70 °C ~+150°C

Humidity Range

20 ~ 98&R.H.

Temp. constancy

±0.5ºC

Humidity constancy

±2.5%R.H

Humidity uniformity

±3.0%R.H

±5.0 % R.H

Heat uptime

-70°C ~ +100°C, within 60 min

Pull downtime

+20°C ~ -70°C, within 80 min

Equipment Power

9.5KW

10.6KW

18.5KW

18.5KW

Ambient Temp.

5ºC ~+35ºC

Standard accessories

Sight window*1, cable port(port 50mm)*1, shelves*2, chamber lamp*1, power cable *2m

Safety device (standard)

No fuse breaker, overpressure overheat and over current protection for compressor,

Over temp. protect, overload protect of the blower, dry heat protection

Control System

Balanced Temperature & Humidity Control System

Refrigeration system

Air Cooled (Water Cooled Type is an option)

Hermetic compressor, Cascade Refrigeration

CFC-Free refrigerant(HFC-507/HFC-23)

Controller

Panel:7-inch LCD Touch panel, Chinese or English display selectable

Operation model: Program or fixpoint running

Memory capacity :120programs,1200steps,

All repeat 999 cycles, part repeat 99 cycles

Interior material

Stainless Steel Plate ( SUS 304 )

Exterior material

Baked Painting Steel Or Stainless steel(SUS304)

Insulation material

Rigid polyurethane Foam and Glass Fiber Wool

System

Balanced & Humidity Control System

Wiring method

AC 380±10 % 50Hz,3 phase 4 wires +Ground Wires

Note:
1. We reserve the right to change specifications, without prior notice
2. Customized sizes and configurations available

Besides this, we have a lot of other chambers for your reference:

3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. and Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/  humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt Spray Chamber
Two wings Drop Tester
Vibration Testing Machine

FAQ

Q1: What is the Warranty for the accelerated aging machine?

A1: For the accelerated aging machine, we offer a 1-year warranty service. If any quality problems on our side occurred in this period, we will send you a replacement and cover the cost of shipping and component parts.

Q2: What's the delivery term?

A2: Usually, it takes us 20 - 25 days after order confirmation to produce the equipment and a little bit longer for customization service. While if you are in urgent need, we can make special arrangements to speed up the proceedings. Then we start the shipped by sea, by air freight or by air express.

Q3: What's the payment term?

A3: T/T, L/C, and other payment terms could be negotiated.

Q4: Is it ok for the customization service?

A4: Yes, the inner chamber dimensions, structure, color, some special parameters can be customized as per your specific request.
