100kn Tensile Tester Computer Servo Strength Tester for Plastic Testing
Dongguan Xin Bao Instrument Co., Ltd.- Mass Scope of Workpiece：<900kg
- Type：Tensile Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
Base Info
- Model NO.：XB-OTS-600A
- Display：Digital, LCD ( Linkable to PC )
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Max.Acceleration(G)：17
- Max Capacity：2, 5, 10, 20, 50, 100, 200, 500kgf Can Be Setting
- Motor：Servo Motor
- Test Speed：1~500 mm,Min Selectable
- Stroke Resolution：0.1mm
- Test Stroke：600mm (Without Grips)
- Force Precision：±0.5%
- Transport Package：Standard Strong Wood Case
- Specification：580*580*1250mm
- Trademark：OTS
- Origin：Guangdong, China (Mainland)
- HS Code：90248000
- Production Capacity：248 Sets Per Month
Description
Displacement Control:Displacement encoder count with four frequency technology
So that the displacement of four times
the resolution can up to 0.0005mm
Force system: servo drives + Servo motor + precision ball screw drive
Control system:Mechanical transmission + TM2101 + Pulse Command and Control System control
Measurement and Control System : TM2101 and control system; master controller uses the most advanced 32-bit ARM processor in the 21st century, the processing speed of the Pentium-class common computer standards, compared to the traditional 8 yuan SCM control system overall performance greatly improved, faster operation, control accuracy higher
Obtain data: The key components are used America's most stable and ultra-precision 24 yuan AD, sampling rate of up to 2000 times / sec, can capture the power of instantaneous change process, the entire file, regardless of the resolution of up to 1,000,000 indexing
Software functions:
1. Use windows working platform, set all parameter with dialog forms and operate easy;
2. Using a single screen operation, do not need to change the screen;
3. Have simplified Chinese, traditional Chinese and English three languages,switch conveniently;
4. Plan test sheet mode freely;
5. Test data can be directly appeared in the screen;
6. Compare multiple curve data through translation or contrast ways;
7.With many units of measurement, the metric system and british system can switch;
8.Have automatic calibration function;
9.Have user-defined test method function
10.Have test data arithmetic analysis function
11. Have the function of automatic magnification, to achieve the most appropriate size of graphics
Corresponding Standard:
ASTM D903,F2258,GB/T 2790/2791/2792, CNS-11888,JIS K6854,GB/T 6329,BS EN 14410-2003,YY/T 0729,GOST 21751 and other standards.
Packing & Shipping
1.Strong standard wood case, inner plastic films wrapped for ensile Strength Testing Machine
2. Usually we delivery the equipment by air,by sea or by express. it depends on customer
FAQ:
Q1 :Can you customize the product?
A:Yes, we can customize any products according to requirements.Hot selling lab electronic temperature humidity cabinet/Environmental climate test chamber also can be customized.
Q2 :How to choose the most suitable products?
A:Our professional team will give you the best suggestion,just be patiently to tell us the information about the parameters your required.
Q3 :Can you arrange installations and commissioning in our lab?
A:Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate
Secondly;We had detailed operation manual with chamber , any problems you can find and solve in it
Thirdly, some of customized chambers we should to install and teach your team to operate .
If you want to know more information...
Please leave a message below and click " SEND "
Thanks for your time and attention~Thank you!
