Biobase Digital Seal Tester, Leakage Tester Detector
Biobase Meihua Trading Co., Ltd.- After-sales Service：Online
- Warranty：One Year
- Max Diameter of Workpiece：500mm
- Mass Scope of Workpiece：10000kg
- Type：Leakage Testing
- Accuracy Grade：0.1kpa
Base Info
- Model NO.：BK-ST134
- Load Way：Electronic Load
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Vacuum Degree Range：-90~0kpa
- Vacuum Precision：0.1kpa
- Resolution：0.1kpa
- Indication of Changes：<=1%
- Vacuum Chamber Size：Diameter 270mm*210 mm
- Operation Host (W*D*H)：320*420*120mm
- Original Air Pressure：0.7MPa (Owned)
- Original Air Connection：Diameter 6 Polyurethane Pipes
- Control Method：Microcomputer Control, Automatic Test Procedure
- Transport Package：International Standard Box
- Specification：diameter 300*350 mm
- Trademark：BIOBASE
- Origin：China
- Production Capacity：300units,Month
Description
Model
BK-ST134
Vacuum Degree Range
-90~0kPa
Vacuum Precision
0.1kPa
Resolution
0.1kPa
Indication of Changes
≤1%
Vacuum Chamber Size
Φ270mm×210 mm( standard)
Note: customization is available for other sizes
Original Air Pressure
0.7MPa(Owned)
Original Air Connection
Φ6Polyurethane pipes
Control Method
Microcomputer control, automatic test procedure
Display
LCD display
Dimensions
Sealedvacuumchamber:Φ300*350 mm
Operation Host (W*D*H): 320*420*120mm
Environmental Conditions
RT(20±10)ºC,
Relative humidity<85%
Power Supply
AC110 /220V±10%,50/60Hz
Optional Accessories
Vacuum Chamber:Φ360 mm x 585 mm (H)
Vacuum Chamber:Φ460 mm x 330 mm (H)
JW-032B Air Compressor
Package Size(W*D*H)
400*620*600mm
Net Weight/ Gross Weight
16kg/21kg
