Ep Hipot Electric Portable Current Injection Tester 500 to 2000AMPS
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Accuracy Grade：0.5
- Display：Digital
Base Info
- Model NO.：EPS-PCIT
- Control：Manual Control
- Weight：0-100Kg
- Power Source：at Customized
- Input Voltage：220V,380V at Customized
- Output Current：2000A
- Screen：Digital Display
- Primary Current Range：0 ~ 2000A
- Resolution of Primary Current Range：0.1A
- Secondary Current Range：0~6A
- Resolution of Secondary Current Range：0.001A
- Accuracy：RMS+-0.5%
- Dual Protection：Overload Electronic Protection and Software Protec
- Operating Environment：Temperature -10-40degree
- Relative Humidity：< 80%
- Volume：430mm * 260mm * 260mm
- Autotransformer：Is Adjustable
- Transport Package：Plywood Case
- Specification：430mm * 260mm * 260mm
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030339000
- Production Capacity：1000,Year
Description
Design TypeRegulator Current Injector Current(A) Voltage(V) Current(A) Voltage(V) EPS-PCIT 500A 3 3 13.60 220 500 6 Box EPS-PCIT 1000A 6 6 27.00 220 1000 6 Box EPS-PCIT 1500A 9 9 40.00 220 1500 6 Box EPS-PCIT 2000A 12 12 54.50 220 2000 6 Box EPS-PCIT 2500A 15 15 39.50 380 2500 6 Bench EPS-PCIT 3000A 18 18 47.30 380 3000 6 Bench EPS-PCIT 4000A 24 24 63.00 380 4000 6 Bench EPS-PCIT 5000A 30 30 79.00 380 5000 6 Bench EPS-PCIT 6000A 36 36 95.00 380 6000 6 Bench EPS-PCIT 7000A 42 42 110.50 380 7000 6 Bench EPS-PCIT 8000A 48 48 126.00 380 8000 6 Bench EPS-PCIT 10000A 60 60 158.00 380 10000 6 Bench EPS-PCIT 15000A 90 90 236.80 380 15000 6 Bench
Please contact EP Hipot Electric for more details on China Portable 2000A Primary Current Injection Test Kit.
