• Model NO.：GY
• Loading Method：Dynamic Load
• Display：Needle
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Control System：PLC Control
• Color：White,Blue
• Warranty：2 Years
• Using Life：More Than 15 Years
• Name：Rubber Rheometer Rotorless Gold Testing Machine Pr
• Temperature Range：Normal-200 Degree Centigrade
• Temperature Rising Time：Below 10min
• Torque：0-20n.M
• Dimension：625*600*1250mm
• Printer：A4 Color Ink-Jet Printer
• Transport Package：Wooden or as Required
• Specification：CE, SGS, ISO
• Trademark：chaoguangyue
• Origin：China Qingdao
• HS Code：84778000
• Production Capacity：30 Sets Per Month

Basic Info.

Model NO. GY Loading Method Dynamic Load Display Needle Control Computer Control Weight 0-100Kg Power Source AC380V Oil Cylinder Position Under Control System PLC Control Color White,Blue Warranty 2 Years Using Life More Than 15 Years Name Rubber Rheometer Rotorless Gold Testing Machine Pr Temperature Range Normal-200 Degree Centigrade Temperature Rising Time Below 10min Torque 0-20n.M Dimension 625*600*1250mm Printer A4 Color Ink-Jet Printer Transport Package Wooden or as Required Specification CE, SGS, ISO Trademark chaoguangyue Origin China Qingdao HS Code 84778000 Production Capacity 30 Sets Per Month

Product Description

Rubber Rheometer Rotorless Gold Testing Machine Price

Specifications:
1. gold Testing Machine price.
2.Computer controlling system.
3.Inteligent digital temperature instrument.
4.computer screen shows data.
5. CE ISO SGS.

Features:
This machine is used to measure the characteristics of unvulcanized rubber and find out the most suitable time for rubber vulcanization. Adopt computer control and interface board for data collection, storage, processing and printing the results; the more powerful. Also it has the curve comparison, amplification, and other functions.

A. high precision sensors: 0 ~ 20 n. m.Resolution: 0.001 N.m.

B. control system: adopting computer control and interface board for data collection, preservation, processing and printing test results and curve processing.

C. rotation system: adopting step Electronics control motor + amplitude regulator.DHS swing Angle: + / - 0.5 DHS plus or minus 1.
D. the temperature control system: adopting Inteligent digital temperature control instrument, Automatism adjust PID control parameters in real time.
Temperature control range of 0-200 °C, the temperature control precision of plus or minus 0.3 °C, the temperature resolution 0.1 °C or less.

E. data transmission mode, RS232 transmission

F. display mode: Vulcanize - 105 + Windows XP test software, according to the computer screen with excellent user software and advanced hardware equipment makes the whole measurement is very convenient, fast, accurate, and pleasant.

G. cavity: Cr6wv material, in line with the GB/T16584-1996 standard requirement.

F. measuring way: humanistic way of measurement and control, mouse click the box or host panel light touch button two test modes

Main technical parameters:


temperature measuring range	0 °C to 200 °C
temperature measuring accuracy	plus or minus 0.3 °C or less
temperature control precision	plus or minus 0.3 °C or less
the temperature resolution	0.1 °C
torque range	0-10 n. m 0-20 n. M
moment resolution	0.001 N.m
cavity frequency	1.7 Hz
amplitude	+ / - 0.5 DHS DHS plus or minus 1
the environment temperature	0 to 35 °C relative humidity < 80%
vulcanization time setting range	min. 2-300
distribution	0.5 MPa
power	ac 220 v, 800 w

Our certifications:
