Portable Transformer DC Winding Resistance Tester Epwt20A/Epwt40A/Epwt50A
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Type：Universal Testing Machine
- Accuracy Grade：0.2
- Display：LCD Touch Screen
- Control：Computer Control
Base Info
- Model NO.：EPWT
- Weight：18kg Including Test Leads and Clamps
- Power Source：110V or 220V at Customized
- DC Test Current：up to 100 a Maximum
- Test Current：5A, 10A, 20A, 40A, 50A60A 100A
- Battery：10A Tester Can Equipped with Battery
- Measuring Precision：+-0.2
- Data Storage：1000 Groups
- Communication Port：RS232, USB
- Pinter：Built-in Thermal Printer
- Max. Resolution：0.1 Uomega
- Fuse：5A
- Controlled by：High Speed Scm
- Protection Functions：Full
- Key Words：Transformer Ohmmeter
- Temperature：-20c~40c
- Humidity：<80%Rh, No Condensation
- Built-in：Thermal Printer
- Transport Package：Plywood Case with Foal and Waterproof Plastic
- Specification：L325mm * W240mm * H275mm
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030332000
- Production Capacity：2000,Year
Description
±0.2%(±2digits)Data storage 1000 groups Resolution 0.1μΩ Power source AC 220V±22V,50Hz±2 Hz Fuse 5A Working condition Temperature:0°~40°
<90% RH, no condensation Oversize L400×W225×H350 mm Weight 18kg With leads and clamps Working Condition Temperature: -20ºC~40ºC Humidity: <80%RH, No condensation
More details on EPWT Transformer Winding Resistance Tester, please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
<90% RH, no condensation
More details on EPWT Transformer Winding Resistance Tester, please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
