• Model NO.：KU-1000S
• Temperature Range：-70oc~+150oc
• Humidity Constancy：+,-0.5%
• Cooling Rate：0.7oc~1.0oc,Min
• Pressure Range：Normal Pressure~11.6kpa
• Pressurized Parts：High Quality Steel Plate(Rust Proof&Plastic Spray
• Insulation Material：High Quality Glass Wool
• Heater：Iron-Chrome Wire Heater
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：100-500kg

Specifications ModelKU-504LKU-1000LKU-504SKU-1000SInner Size (D*W*H)mm800*700*9001000*1000*1000800*700*9001000*1000*1000Capacity ( KW )11151618Chamber Volume ( L )50410005041000PerformanceTemp range-40 ºC~ +150 ºC-70 ºC~ +150 ºCTemp constancy±0.5 %Temp deviation≥ 100 ºC, ±3.0 ºC( at constant pressure with empty load )< 100 ºC, ±2.0 ºC( at constant pressure with empty load )Cooling rate0.7 ºC~ 1.0 ºC /min ( Overall average )Pressure rangeConstant pressure  ~ 11.6kPaPressure constancyWhen  ≥ 40kPa, ±2kPa,     4kPa ~ 40pKa  ±0.5kPa,   when ≤ 4kPa, ±0.1kPaDepressurization rateConstant pressure ~ 1kPa≤30mins ( Normal temp )Pressure recovery rate10kPa/Min(adjustable )MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel ( SUS304 )Pressurized partsHigh quality steel plate(Rust proof & Plastic spray treated)  Insulation materialHigh quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater cooledTemp regulating methodBalanced Temperature & Humidity Control System  (BTHC )PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen Controller  Safety DevicesOver pressure, over heat and over current protection for compressor, over temp. protection,
over load protection for blower,   Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2  PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire. Note:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available Temperature and altitude check controller, 7 inch true color LCD touch screen. Programmable microcomputer PID control SSR output operation.ControllerSystemThe controller operation interface is available in English, and the real-time operation curve can be displayed on the screen.Control mode: heat balance temperature and humidity control mode, using P·I·D+S·S·R system with channel coordination control; With the function of automatic calculation, the temp and humidity changing conditions can be corrected immediately, making the temperature & humidity control more accurate and stable.Temperature altitude test chamber has the capacity of 120 programs, 99 segments per group and 999 steps per cycle, and the maximum value of each period is 99 hours and 59 minutes.U disk can be inserted at any time to export or upload data, and can be presented with software in the computer to view or into Excel format.The meter is equipped with USB port, which can be directly driven by the port to preview and print micro printer.The temperature altitude device has a powerful network monitoring, control network functions, even if you are not next to the machine, you can also operate on the computer, real-time monitoring. Be familiar with the operation of the altitude test chamber.The controller panel is equipped with a 10M/100M Ethernet interface, which can automatically obtain the IP address for remote control. It can support real-time monitoring, history curve playback, program editing, FTP upload and download, history failure view, remote fixed value/program control and other functions.Auxiliary Functions: Fault alarm and reason, Processing prompt function; Power off protection function; Upper and lower limit temperature protection function; Calendar timing function (automatic start and automatic stop), Self-diagnostic function.
