• Model NO.：YPO-480
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC380V
• Inner Size：800*1000*600mm
• External Size：1200*1700*840mm
• Volume：600 Liters
• Temp. Fluctuation：+,-0.3 Degree
• Color：Ivory
• Interior Chamber Material：SUS#304 Stainless Steel Plate
• Exterior Chamber Material：Stainless Steel Plate + Powder Coated
• Circulation System：Circle Fan
• Indication Resolution：0.1degree , 1 Degree
• Heat up Time：60 Mins
• Transport Package：Well Packed in Strong Wooden Cases.
• Specification：YPO-600
• Trademark：Yuanyao
• Origin：China
• HS Code：9032100000
• Production Capacity：100 Sets , Month

SpecificationMODELYPO-072YPO-270YPO-480YOP-600YPO-720Internal Sim.WHD(mm)450×400×400600×900×500800×1000×6001000×1000×6001200×1000×600External Dim.W×H×D(mm)750×1200×5501050×1650×7401200×1700×8401400×1750×8401750×1750×840Temp.RangeRoom Temp.+10ºC---+200ºC(300ºC)FerformanceTemp.&Humi,Constancy±0.3ºCTemp.&Humi,Constancy±0.1ºC AT 200ºC;±1.5% AT 300ºCIndication Resolution0.1ºC/1ºCHeat-up Time( min.)Approx.60min.MaterialExteriorIron Sheet+Baked EnamelInteriorSUS#304 stainless steel piateInsulationFiberglass WoolSYSTEMSCirulationCircle FenHeatingChrome Steel Strip Wire HeaterControllerElectric Digital Control+S.S.R.doorSingle-WingDouble-WingOther ComponentsEnvironmental Control Indicator Lights,Experiment Separation Shelves(2 pcs).Sevey DevicesOverheating Prevention Circuit breaker,Control System,Breakdown Indicator Light.Power Source[K.W.]AC 1Ψ 220V ; 3Ψ 380V 60/50Hz Any requested size and TEMP. range(max.1200ºC)will be considered.
