• Model NO.：climate altitude test chamber
• Inner Size (D*W*H)：800*700*900mm
• Temperature Range：-40oc~+150oc
• Humidity Constancy：+,-0.5%
• Cooling Rate：0.7oc~1.0oc,Min
• Pressure Range：Normal Pressure~1kp
• Pressurized Parts：High Quality Steel Plate(Rust Proof&Plastic Spray
• Insulation Material：High Quality Glass Wool
• Pump：Rotary Vane Type Vacuum Pump
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

ModelKU-504LInner Size (D*W*H)mm800D*700W*900HCapacity(KW)11Chamber Volume(L)504PerformanceTemp range-40ºC~+150ºC,-140ºF~+302ºFTemp constancy±0.5%Temp deviation≥100ºC, ±3.0ºC(at constant pressure with empty load)<100ºC, ±2.0ºC(at constant pressure with empty load)Cooling rate0.7ºC~1.0ºC/min(Overall average)Pressure rangeConstant pressure ~1kPaPressure constancyWhen ≥40kPa, ±2kPa,     4kPa~40pKa  ±0.5kPa,   when≤4kPa, ±0.1kPaDepressurization rateConstant pressure~1kPa≤30mins(Normal temp)Pressure recovery rate10kPa/Min(adjustable)MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel(SUS304)Pressurized partsHigh quality steel plate(Rustproof & Plastic spray treated)  Insulation materialHigh-quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater-cooledTemp regulating methodBalanced Temperature & Humidity Control System(BTHC)PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen Controller  Safety DevicesOverpressure, overheat, and over current protection for compressor, over temp. protection, overload protection for the blower, Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2  PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire. Note:
1. We reserve the right to change specifications without prior notice;
2. Customized sizes and configurations available


After-sale service
If you face any problems in the future during the testing process, we promise we will give you a reply within 48 hours and a solution provided within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
