TBTCTM-Y2000 Digital Display Hydraulic Manual Compression Testing Machine

Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.
  • After-sales Service：yes
  • Warranty：one-year
  • Type：Compression Testing Machine
  • Maxcapacity：>1000KN
  • Accuracy Grade：1
  • Load Way：Electronic Load

Base Info

  • Model NO.：TBTCTM-Y2000
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Under
  • Max. Cpacity (Kn)：2000
  • Relative Error：±1%
  • Distance Between Platens：165-280mm
  • Piston Stroke：50mm
  • Piston Diameter：250mm
  • Rated Pressure：40MPa
  • Transport Package：Standard Export Packing
  • Specification：ISO9000
  • Trademark：TBT
  • Origin：Nanjing, China
  • HS Code：90158790
  • Production Capacity：50 Sets Per Month

Description

Overview Product Description

Product Parameters


Technical specification
ModelTBTCTM-Y2000
Capacity2000KN max.
Measuring range0~2000
Relative  error±1%
Pressure  plate  sizeD250*T33mm (round) upper plate
D250*T40mm (round) lower plate
Distance Piece D200*T50mm *3pcs
D200*T77mm *1pc
Maximum distance between upper and lower plate330mm
Piston stroke100mm
Power supply220VAC 50HZ 750W
DimensionsAround 900×400×1000 (L*W*H)
Net weightAround 700kg

Standard packing list

NODescription of goodsQ'ty
1Digital Display Controller1pc
2Protective defence1set
3Micro Printer1pc

4Distance Piece4pcs

     TBTCTM-Y2000 Digital Display Hydraulic Manual Compression Testing Machine
