Full Automatic Triaxial Test Apparatus (TSZ-1)for Soil
Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.- After-sales Service：yes
- Warranty：one-year
- Type：Triaxial Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Mechanical Load
Base Info
- Model NO.：TSZ-1
- Loading Method：Dynamic Load
- Display：Needle
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Specimen：Ø39.1 X 80mm
- Capacity：10kn Maximum
- Strain Rate：0.016-1.6mm,Min. Mechanical Speed with 6 Gears
- Platen Travel：50mm Maximum
- Confining Pressure：0-1MPa
- Back Pressure：0- 0.6MPa
- Pore Pressure：0-1MPa
- Volume Deformation：0-25cm, Minimum Division : 0.1cm
- Axial Displacement：0-30mm (Micrometer)
- Size：Main Unit : 350 X 300 X 1100mm (L x W x H) Control
- Transport Package：Standard Export Packing
- Trademark：TBT
- Origin：China
- HS Code：90158790
Description
Full Automatic Triaxial Test Apparatus is designed for laboratory and educational use as well as institute for civil engineering test. It is a type of strain controlled apparatus to determine the specimen with maximum confining pressure of 1MPa and sample diameter of Ø 39.1 x 80mm. It can perform the strength and deformation characteristics testing of soil specimen under the static axial load and unconsolidated-undrained test (UU), consolidated-undrained test (CU) and consolidated-drained (CD) test.
Product Parameters
Specimen size:
39.1mm
Confining pressure:
0-2MPa
Back pressure:
0-2MPa
Dewatering:
0-50ml
Volume deformation:
0-50ml
Speed:
0-4.8mm/min
Axial force:
0-10KN
Business Fields
Packaging
Clients Feedbacks
FAQ
1. How long is the delivery time?
Normally goods will be shipped out within 7-10days after contract signed and down payment received.
2. Is it possible to make our own brand/logo on your product?
Yes, but depends on MOQ.
3. What's your MOQ?
This depends on different types of products. If it is a large machine, the MOQ is usually 1 set. For small instruments, such as thermometers, the MOQ is 50 pieces.
4. What kind of payment term you accept?
Normally,
1) If total contract value less than USD 10,000.00 : 100% T/T in advance after contract signed.
2) If total contract value more than USD 10000.00 : 50% T/T in advance after contract signed and 50% T/T after receipt of BL copy. Or, irrevocable LC is acceptable.
