• Model NO.：TH Series
• Humidity Falling：Approx. 0.3~1.0 C,Min
• Compressor：Germany Brand
• Cooling Fan：Stainless Steel
• Application：Lithium-Ion Battery
• Transport Package：Wooden Case
• Specification：TH Series
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：8514109000
• Production Capacity：100 Sets,Month

 TH-150(A~F)  TH-225(A~F)  TH-408(A~F)  Internal Dimension
W*H*D (mm)  400*500*400  500*600*500  600*750*500  600*850*800  Internal Dimension
W*H*D (mm)  950*1650*950  1050*1750*1050  1200*1900*1150  1200*1950*1350  Temperature Range  Low Temperature(A:25degres Celsius   B:0degres Celsius
C:-20degres CelsiusD:-40degres Celsius  E:-60degres Celsius
F:-70degres Celsius)
High Temperature 150degres Celsius  Humidity Range  20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional , need Dehumidifier)  Indication relolution/
Distribution uniformity
of temperature and humidity  0.1degres Celsius; 0.1% R.H/±2.0degres Celsius; ±3.0% R.H. Control Accuracy of
Temperature and Humidity  ±0.5degres Celsius; ±2.5% R.H. Temperature Rising/
Falling Velocity Temperature rising approx.  0.1~3.0degres Celsius/min ;
 temperature falling approx.  0.3~1.0degres Celsius/min;
 ( Falling Min.1.5 degres Celsius/min is optional) Inner and Outer Material Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE
cold-rolled steel with paint coated.  Insulation Material  Resistant to high temperature, high density, formate chlorine, ethyl acetum foam
insulation materials   Cooling System  Wind cooling or water cooling, (single segment compressor-40degres Celsius,
double segment compressor -70degres Celsius)  Protection Devices  Fuse-free switch, overloading protection switch  for compressor, high and low
voltage coolant protection switch, over-humidity and over-temperature protection
switch, fuses, fault warning system, water short storage warning protection  Optional Accessories    Inner door with operation hole , Recorder, Water Purifier, Dehumidifier  Compressor  French Tecumseh Brand, Germany Bizer Brand  Power  AC220V 1Ph 3 lines, 50/60HZ ,  AC380V 3Ph 5 lines , 50/60HZ  Appro*. Weight (Kg)  150  180  250  320

Temperature Humidity Test Equipment Features:
1. Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning, and the space between the shelves in the chamber is adjustable.
2. Microprocessor controller for temperature and humidity ensures of precise and reliable control Imported compressor.
3. Independent temperature-limiting alarm system ensures experiments run safely.
4. Printer connector and RS485 connector are options which can connect printer and computer to record the parameters and the variations of temperature.(optional)
5. There is a 50mm instruction connection hole on the left side of the chamber for easy testing operation and temperature measurement.

Pictures for reference:

More Programmable Temperature Humidity Testing Equipment for Lithium-Ion Battery Test information, please contact us.
