Pd Free Partial Discharge Free Detector
Sansion Power Electric Co., Ltd.- Type:Universal Testing Machine
- Maxcapacity:<1000KN
- Accuracy Grade:0.5
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:LCD
Base Info
- Model NO.:SXJF-2009
- Control:Computer Control
- Weight:0-100Kg
- Power Source:AC 110V,220V at Customized
- Oil Cylinder Position:Under
- Test Channels:3 Channels
- Tested Capacity Range:6PF-250UF
- Transport Package:Plywood Case
- Specification:ISO9001 SGS
- Trademark:Sansion
- Origin:Wuhan, China
- HS Code:9030339000
- Production Capacity:100 Units
Description
Input Unit Nbr.
Turning Capacitance
Sensitive Degree(pC)
(unsymmetrical circuit)
Allowed Current RMS
Unbalanced Circuit
Balanced Circuit
1
0~25~100PF
0.02
30mA
0.25A
2
25~100~400PF
0.04
50mA
0.5A
3
100~400~1500PF
0.06
120mA
1A
4
400~1500~6000PF
0.1
0.25A
2A
5
1500~6000~25000PF
0.2
0.5A
4A
6
0.006~0.025~0.1μF
0.3
1A
8A
7
0.025~0.1~0.4μF
0.5
2A
15A
8
0.1~0.4~1.5μF
1
4A
30A
9
0.4~1.5~6.0μF
1.5
8A
60A
10
1.5~6.0~25μF
2.5
15A
120A
11
6.0~25~60μF
5
25A
200A
12
25~60~250μF
10
50A
300A
7R
Resistance
0.5
2A
15A
√ Amplifier frequency range
(1)Low terminal:10KHZ, 20KHZ, 40KHZ optional
(2)High terminal:80KHZ, 200KHZ, 300KHZ optional
√ Amplifier gain adjustment
Coarse adjusting: 6 positions, 20±1dB between every position. Fine adjusting range≥20dB.Data is 10 times between every position, for example: if the test data of the third position is 98, the second position data is 9.8. If the third position data is over 120, the operator should adjust it to the second position then do the test, and the data should be multiplied by 10, that is the final real test value.
√ Time window
Window width: 15°-150°
Every window is rotatable 0°- 170°
Two time windows can be opened separately or at same time.
√ Discharging Meter
(1) Pointer type:
Logarithmic scale:1-10-100 Error<±5%(full scale)
Linear scale:0-100 Error<±5%.
(2) Digital type:3 1/2 digits LED
0-100 Error<±3%(full scale)
√ Elliptical time base
(1) Frequency:50HZ,100HZ,150HZ,200HZ,400HZ,
(2) Ellipse rotate:30°as one position, can rotate 120°
(3) Display:Ellipse- straight line
√ Voltmeter:
(1)Range:100KV
(2)Display: 3 1/2 digits LED
(3)Accuracy:better than ±3%(full scale)
√ Oversize: 530×550×220(W×D×H)mm3
√ Weight:About 22Kg
Warranty: One year quality guarantee after shipment.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
