• Model NO.：SXWH
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Testable Voltage：0.22kv-500kv
• Transport Package：Carton or Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9031809090
• Production Capacity：100 Units

Auto power off:15 minutes standby then auto power off.Sample rate:3 times/second.Build-in power supply:the control unit battery model is NEDA/604/6F22,9V or same style battery. X and Y collectors batteries are AG13,1.5V.Working conditions:-35ºC- +50ºC, humidity: ≤90%RH.Storage conditions:-40ºC- +55ºC, humidity: ≤95%RH.Accuracy:self calibrating error ≤2°. On-site testing: same phase error≤10°,out of phase≤15°.Power supply:9V±2VCollectors X and Y supply:7.5V±1.5V.Control unit working current:≤ 7mA.Collectors X and Y working current:≤ 4mA.Line-of-sight transmission distance between collector X, Y and control unit ≤ 70m.Testable voltage degree:0.22KV-500KV.Extensible insulating rod:min. length is 600mm, max. length is 3000mm.Carry case oversize:(L×W×H) 650mm×250mm×100mm.Weight:Control unit about 0.3Kg, total about 5Kg.Accessories:1 piece Aluminum alloy carrying case
1 piece test lead with AC 220V plug and clip
1 piece User's Guide
1 piece Test Report

Warranty: One year quality guarantee after shipment.

More information, please kindly contact with us, we can recommend the suitable test set according your requirements and give you the best quotation. Thank you!
