• Model NO.：SXZGF Series
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Output Voltage：Customized
• Power Supply：AC 220V±10%;50Hz
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Units



60/2

100/2

150/3

160/2

180/2

200/5

250/2

100/200
3/2

200/300
3/2

Others

Output Voltage
(kV)

60

100

150

160

180

200

250

100/200

200/300



600~800kV fur customized

Output Current(mA)

2

2

3

2

2

5

2

3/2

3/2

Output Power(W)

120

200

450

320

360

1000

500

400

600

Charging Current
(mA)

3.0

3.0

12.0

3.0

3.0

3.0

3.0

4.5/3.0

4.5/3.0

Control Unit Weight(kg)

4.3

4.3

5.3

4.3

4.3

4.4

4.5

4.5

8.1

Doubler Size(mm)

Φ80
×500

Φ80
×620

Φ80
×770

Φ80
×770

Φ110
×770

Φ110
×770

Φ110
×820

Φ110
×800

Φ110
×1350

Doubler Weight(kg)

6.3

6.8

7.5

7.2

7.2

7.2

7.6

7.5

12.6

HV polarity:

Negative voltage polarity, Zero start, Continuously adjustable.

Power Supply:

AC 220V±10%;50Hz

Voltage measurement error:

1.0% ±1 digit, Max. resolution: 0.1%kV

Current measurement error:

1.0% ±1digit, Max. resolution: 0.1%uA

Overvoltage setting error:

≤1.0%

0.75 switching error:

≤0.5%

Ripple coefficient

≤1.0%

Voltage Stability:

Stochastic wave ≤0.5% when power wave is ±10%,

Duty:

Rated load: 30mins.;1.1 times rated voltage:10mins

Working Temperature:

-15ºC~50ºC

Relative Humidity:

When temperature is at 25ºC, less than 90%(no condensation)

Altitude:

Below 2500M

Warranty: One year quality guarantee after shipment.


More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!

Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
