15kV Insulation Resistance Tester
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Accuracy Grade：5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
Base Info
- Model NO.：GD3126E
- Weight：8.5 kg
- Power Source：AC220V
- Rated test voltage：0.5kV, 1.0kV, 2.0kV, 2.5kV, 5.0kV, 10kV, 15kV
- Output voltage error：±5%
- Resistance range：100GΩ~5TΩ
- Accuracy class：5.0 class
- Short circuit current：Approx. 5mA
- Transport Package：Standard Export Wooden Box
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan, China
- HS Code：9030332000
- Production Capacity：2000set,Year
Description
Rated test voltage steps
GD3126
0.5kV ~ 20kV
Output voltage error
±5%
Resistance range
Upper limit
100GΩ~5TΩ
Lower limit
0.1MΩ
Accuracy class
5.0 class
Lower half range basic error
±( 5%•Rx + 1d )
Upper half range basic error
±( 10%•Rx + 2d )
High voltage display error
±( 5%•Ux + 1d )
Temperature measuring error
±0.5ºC
Humidity measuring error
±2%RH
Short circuit current
Approx. 5mA
Voltage ripple
<3%
Insulation resistance
> 500 MΩ (between test wire and case)
Withstand voltage
AC10.0kV 50Hz 1min (between test wire and case)
Power supply
14.8V lithium battery
Battery service time after one charging
30days 10times DAR & 5times PI test per day
Working temperature and humidity
0ºC ~ + 40ºC < 85%RH
Storage temperature and humidity
- 20ºC ~ + 50ºC < 90%RH
Dimension (mm)
460 (L)*380(W)*190(H)
Weight
8.5kg
