• Model NO.：KM-500C
• Temp. Range：50oc~200oc or 300oc
• Heat up Time：50oc~200oc Within 50 Mins
• Type：Material Testing Machine
• Weight：100-500kg
• Power Source：AC380V
• Inner Materials：Stainless Steel
• Transport Package：Strong Plywood Case, Meet International Standard
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Guangdong, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Yesr

Model DescriptionWE-LY- 500CWE-LY- 1000CInternal Dimension  WxHxD (mm)800*800*8001000*1000*1000External Dimension WxHxD (mm)1400*950*17101600*1150*1910Sprya NozzleΦ0.4mm, Φ0.5mmΦ0.5mm, Φ0.8mmRotating TableDiameter 500mmDiameter 600mmTable Height400 mm, Samples Load: 5 Kgs400 mm, Max Load: 10 KgsGross Weight (Kgs)205 Kgs285 KgsVoltage (Power)AC 1Ψ 220V 50HzAC 3Ψ 380V 60HzRain of Pipe-Swing TestIP x3 IP x4 Swing Pipe: RT~+28°CFlow:0.07L/min Per NozzleSwing PipeRadius 300mmRadius 500mmWater Flow Speed0.05~0.07L/min0.05~0.08L/minRotating Speed of Rotating-Plate1~5 RPM /Adjustable1~5 RPM /AdjustableTest StandardJIS, ISO, IEC60529, DIN40050,GB2423, GB4208 Standard

Main technical specifications2.1 Interior sizeL 800mm× D 800mm× H1050mm 2.2 Raindrop areaL600× D 600mm* H 40mm2.3 Exterior size Approx L1250 X D 1000X H1750MM2.4 RainfullI-5 mm/min(±0.5mm/min)2.5 Flow adjustment methodManual adjustment2.6 Raindrop Lifting methodNot lifting (fixed)2.7Test time0~999min2.8Turntable lifting height350-700 mm2.9 Turntable Load bearing50KG2.10Table tilting angle°or 15° (horizontal direction)2.11Table Speed 1 r/min(IPX1)2.12 Drip hole diameterΦ0.4mm2.13 Distance between nozzles20×20mm2.14 Turntable dimensionΦ600mm
